TB 290-2 Takeuchi excavator specs & Dimensions (2024 - 2026)

Weight: 8.4t – Transport length: 6.53m – Transport width: 2.2m – Transport height: 2.55m – Bucket capacity: 0.245m³ – Track width:…

Weight: 8.4t – Transport length: 6.53m – Transport width: 2.2m – Transport height: 2.55m – Bucket capacity: 0.245m³ – Track width: 450mm

Check out detailed specifications, information and technical data for Takeuchi TB 290-2 excavator manufactured between 2024 - 2026. Get more in-depth insight with Takeuchi TB 290-2 digger specifications. See information, like: Weight: 8.4t – Transport length: 6.53m – Transport width: 2.2m – Transport height: 2.55m – Bucket capacity: 0.245m³ – Track width: 450mm and more.

Crawler Excavators Takeuchi TB 290-2

Technical specs - TB 290-2 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.4 t
Transport length
6.53 m
Transport width
2.2 m
Transport height
2.55 m
Bucket capacity
0.245 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
6.95 m
Dredging depth
4.23 m
Tear-out force
59.1 kN
Model series
TB
Engine manuf.
Yanmar
Engine type
4TNV98CT
Engine power
51.6 kW
Displacement
3.318 l
Revolutions at max torque
2000 rpm
Max. torque
308/1300 Nm
Emission level
Tier 4 / V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB 290-2 FAQ

When was the Takeuchi TB 290-2 manufactured?

The Takeuchi TB 290-2 was first produced in 2024.

How much does the Takeuchi TB 290-2 weigh?

The Takeuchi TB 290-2 weighs 8.4 tons.

What are the transport dimensions of the Takeuchi TB 290-2?

The Takeuchi TB 290-2 has a transport length of 6.53 meters, a transport width of 2.2 meters, and a transport height of 2.55 meters.

What is the track width of the Takeuchi TB 290-2's undercarriage?

The Takeuchi TB 290-2 has a track width of 450 mm.

What are the excavation performance specifications of the Takeuchi TB 290-2?

The Takeuchi TB 290-2 has a dredging depth of 4.23 meters, a maximum horizontal reach of 6.95 meters, and features a monobloc boom.

What power ratings are available for the Takeuchi TB 290-2?

There are no power rating specifications available for the Takeuchi TB 290-2 in the provided data.

What is the bucket capacity of the Takeuchi TB 290-2?

The bucket capacity of the Takeuchi TB 290-2 is 0.245 cubic meters.

How much is a Takeuchi TB 290-2 Crawler excavator (2024u20132025) worth?

The residual value of the Takeuchi TB 290-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
