Technical specs - TB 2150 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.095 t
Transport length
7.82 m
Transport width
2.49 m
Transport height
2.96 m
Bucket capacity
0.45 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.32 m
Dredging depth
5.195 m
Tear-out force
47.1 kN
Model series
TB
Engine manuf.
Deutz
Engine type
TCD3.6 L4
Engine power
85 kW
Displacement
3.621 l
Revolutions at max torque
2000 rpm
Max. torque
460/1600 Nm
No. of cylinders
4
Emission level
EU V / EPA Tier 4

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB 2150 FAQ

When was the Takeuchi TB 2150 manufactured?

The Takeuchi TB 2150 was first produced in 2024.

How much does the Takeuchi TB 2150 weigh?

The Takeuchi TB 2150 weighs 15.095 tons.

What are the transport dimensions of the Takeuchi TB 2150?

The Takeuchi TB 2150 has a transport length of 7.82 meters, a transport width of 2.49 meters, and a transport height of 2.96 meters.

What is the track width of the Takeuchi TB 2150's undercarriage?

The Takeuchi TB 2150 has a track width of 500 mm.

What are the excavation performance specifications of the Takeuchi TB 2150?

The Takeuchi TB 2150 has a dredging depth of 5.195 meters, a maximum horizontal reach of 8.32 meters, and is equipped with a monobloc boom.

What are the power ratings of the Takeuchi TB 2150?

The available data does not provide power ratings for the Takeuchi TB 2150.

What is the bucket capacity of the Takeuchi TB 2150?

The bucket capacity of the Takeuchi TB 2150 is 0.45 cubic meters.
