Technical specs - SWE155UF Sunward

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.5 t
Transport length
7.91 m
Transport width
2.6 m
Transport height
2.945 m
Bucket capacity
0.61 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.37 m
Dredging depth
5.525 m
Tear-out force
100 kN
Model series
SWE
Engine manuf.
Cummins
Engine type
F3.8
Engine power
90 kW
Displacement
3.8 l
Revolutions at max torque
2200 rpm
Max. torque
500/1500 Nm
Emission level
Euro V / US IV

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No
