SWE 70 Sunward excavator specs & Dimensions (2006 - 2020)

Sunward SWE 70 is a Crawler Excavator manufactured from 2006 to 2020, with a weight of 6.41 tons. It has a transport length of 5.9…

Sunward SWE 70 is a Crawler Excavator manufactured from 2006 to 2020, with a weight of 6.41 tons. It has a transport length of 5.985 meters, a transport width of 2.08 meters, and a transport height of 2.72 meters. The machine features a tear-out force of 44 kN and includes special equipment such as air conditioning and track adjustment.

Crawler Excavators Sunward SWE 70

Technical specs - SWE 70 Sunward

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.41 t
Transport length
5.985 m
Transport width
2.08 m
Transport height
2.72 m
Bucket capacity
0.26 m³
Undercarriage
SL
Boom
MB
Max. Reach horizontal
6.14 m
Dredging depth
2.723 m
Tear-out force
44 kN
Model series
SWE
Engine manuf.
Yanmar
Engine type
k.A.
Engine power
42.9 kW
Displacement
3.32 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., track width, bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Sunward SWE 70 FAQ

When was the Sunward SWE 70 manufactured?

The Sunward SWE 70 was manufactured from 2006 to 2020.

How much does the Sunward SWE 70 weigh?

The Sunward SWE 70 weighs 6.41 tons.

What are the transport dimensions of the Sunward SWE 70 crawler excavator?

The Sunward SWE 70 has a transport length of 5.99 meters, a transport width of 2.08 meters, and a transport height of 2.72 meters.

What type of undercarriage does the Sunward SWE 70 have?

The Sunward SWE 70 has a standard undercarriage.

What are the excavation performance specifications of the Sunward SWE 70 crawler excavator?

The Sunward SWE 70 crawler excavator has a dredging depth of 2.723 meters, a maximum horizontal reach of 6.14 meters, and is equipped with a monobloc boom.

What are the power ratings of the Sunward SWE 70?

The source data does not provide power rating information for the Sunward SWE 70.

What is the bucket capacity of the Sunward SWE 70 excavator?

The Sunward SWE 70 excavator has a bucket capacity of 0.26 cubic meters.

How much is a Sunward SWE 70 Crawler excavator (2006u20132020) worth?

The residual value of the Sunward SWE 70 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
