SH135XU-3B Sumitomo excavator specs & Dimensions (2017 - 2026)

Sumitomo SH135XU-3B is a Crawler Excavator manufactured since 2017, with a weight of 14.8 t and a track width of 600 mm. It has a …

Sumitomo SH135XU-3B is a Crawler Excavator manufactured since 2017, with a weight of 14.8 t and a track width of 600 mm. It has a transport length of 7.54 m, a transport width of 2.49 m, and a transport height of 2.87 m. The excavator features a tear-out force of 89 kN, a dredging depth of 4.96 m, and a maximum horizontal reach of 7.525 m. The bucket width is 0.907 m with a capacity of 0.45 m³. Special equipment includes air conditioning and a blade.

Crawler Excavators Sumitomo SH135XU-3B

Technical specs - SH135XU-3B Sumitomo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.8 t
Transport length
7.54 m
Transport width
2.49 m
Transport height
2.87 m
Bucket capacity
0.45 m³
Track width
600 mm
Max. Reach horizontal
7.525 m
Dredging depth
4.96 m
Tear-out force
89 kN
Bucket width
0.907 m
Model series
SH
Engine manuf.
Isuzu
Engine type
AJ-4JJ1X
Engine power
70.9 kW
Displacement
2.999 l
Revolutions at max torque
1600 rpm
Max. torque
359 Nm
No. of cylinders
4
Cylinder bore x stroke
95.4x104.9 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Sumitomo SH135XU-3B FAQ

When was the Sumitomo SH135XU-3B manufactured?

The Sumitomo SH135XU-3B was first produced in 2017.

How much does the Sumitomo SH135XU-3B weigh?

The Sumitomo SH135XU-3B weighs 14.8 tons.

What are the transport dimensions of the Sumitomo SH135XU-3B crawler excavator?

The Sumitomo SH135XU-3B has a transport length of 7.54 meters, a transport width of 2.49 meters, and a transport height of 2.87 meters.

What is the track width of the Sumitomo SH135XU-3B's undercarriage?

The Sumitomo SH135XU-3B has a track width of 600 mm.

What is the excavation performance of the Sumitomo SH135XU-3B?

The Sumitomo SH135XU-3B has a dredging depth of 4.96 meters and a maximum horizontal reach of 7.525 meters.

What power ratings are available for the Sumitomo SH135XU-3B?

There are no power rating specifications available for the Sumitomo SH135XU-3B in the provided data.

What are the specifications of the primary work tool on the Sumitomo SH135XU-3B?

The primary work tool of the Sumitomo SH135XU-3B has a bucket capacity of 0.45 cubic meters and a bucket width of 0.907 meters.
