E260C SR New Holland excavator specs & Dimensions (2013 - 2026)

New Holland E260C SR is a crawler excavator manufactured since 2013, with a weight of 26 tons. It features a track width of 800 mm…

New Holland E260C SR is a crawler excavator manufactured since 2013, with a weight of 26 tons. It features a track width of 800 mm, a transport length of 8 meters, a transport width of 3 meters, and a transport height of 3 meters. The machine has a tear-out force of 143 kN, a dredging depth of 7 meters, and a maximum horizontal reach of 10 meters. Special equipment includes air conditioning, a blade, cabin adjustment, a diesel particulate filter, and an overload alert system.

Crawler Excavators New Holland E260C SR

Technical specs - E260C SR New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
26.6 t
Transport length
8.98 m
Transport width
3.39 m
Transport height
3.18 m
Bucket capacity min.
0.5 m³
Bucket capacity max.
0.95 m³
Track width
800 mm
Boom
MB
Max. Reach horizontal
10.75 m
Dredging depth
7.38 m
Tear-out force
143 kN
Engine manuf.
Hino Motors
Engine type
JO5E-TI
Engine power
124 kW
Displacement
5.12 l
Revolutions at max torque
1600 rpm
Max. torque
660 Nm
No. of cylinders
4
Cylinder bore x stroke
112 x 130 mm
Emission level
Tier 4

More technical details, like: bucket capacity, undercarriage, bucket width, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

New Holland E260C SR FAQ

When was the New Holland E260C SR manufactured?

The New Holland E260C SR was first produced in 2013.

How much does the New Holland E260C SR weigh?

The New Holland E260C SR weighs 26.6 tons.

What are the transport dimensions of the New Holland E260C SR crawler excavator?

The New Holland E260C SR has a transport length of 8.98 meters, a transport width of 3.39 meters, and a transport height of 3.18 meters.

What is the track width of the New Holland E260C SR's undercarriage?

The New Holland E260C SR has a track width of 800 mm.

What are the excavation performance specifications of the New Holland E260C SR?

The New Holland E260C SR has a dredging depth of 7.38 meters, a maximum horizontal reach of 10.75 meters, and features a monobloc boom.

What is the tear-out force of the New Holland E260C SR?

The New Holland E260C SR has a tear-out force of 143 kN.

How much is a New Holland E260C SR Crawler excavator (2013u20132025) worth?

The residual value of the New Holland E260C SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
