E215LC New Holland excavator specs & Dimensions (2006 - 2026)

New Holland E215LC is a crawler excavator manufactured since 2006, with a weight of 24 tons. It features a track width of 800 mm, …

New Holland E215LC is a crawler excavator manufactured since 2006, with a weight of 24 tons. It features a track width of 800 mm, a transport length of 12.543 meters, and a transport height of 3.168 meters. The machine has a dredging depth of 11 meters and a maximum horizontal reach of 15.818 meters. The bucket width is 1 meter.

Crawler Excavators New Holland E215LC

Technical specs - E215LC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
24.21 t
Transport length
12.543 m
Transport height
3.168 m
Bucket capacity
0.45 m³
Bucket capacity min.
0.45 m³
Undercarriage
LC
Track width
800 mm
Boom
MB
Max. Reach horizontal
15.818 m
Dredging depth
11.85 m
Bucket width
1.5 m
Engine manuf.
N/A
Engine type
N/A
Engine power
118 kW
Emission level
Tier 2

More technical details, like: transport width, bucket capacity max., tear-out force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

New Holland E215LC FAQ

When was the New Holland E215LC manufactured?

The New Holland E215LC was first produced in 2006.

How much does the New Holland E215LC weigh?

The New Holland E215LC weighs 24.21 tons.

What are the transport dimensions of the New Holland E215LC?

The New Holland E215LC has a transport length of 12.54 meters and a transport height of 3.17 meters.

What are the undercarriage specifications of the New Holland E215LC?

The New Holland E215LC has a long undercarriage and a track width of 800 mm.

What are the excavation performance specifications of the New Holland E215LC?

The New Holland E215LC has a dredging depth of 11.85 meters, a maximum horizontal reach of 15.818 meters, and features a monobloc boom.

What are the bucket specifications of the New Holland E215LC crawler excavator?

The New Holland E215LC crawler excavator has a bucket capacity of 0.45 cubic meters and a bucket width of 1.5 meters.

How much is a New Holland E215LC Crawler excavator (2006u20132025) worth?

The residual value of the New Holland E215LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
