E215C EVO New Holland excavator specs & Dimensions (2022 - 2026)

New Holland E215C EVO is a Crawler Excavator manufactured since 2022, with a weight of 22.7 tons. It features a track width of 600…

New Holland E215C EVO is a Crawler Excavator manufactured since 2022, with a weight of 22.7 tons. It features a track width of 600 mm, a transport length of 9.4 meters, a transport width of 2.99 meters, and a transport height of 2.97 meters. The machine has a tear-out force of 188 kN, a dredging depth of 6.65 meters, and a maximum horizontal reach of 9.9 meters. The bucket capacity is 1.2 cubic meters. Special equipment includes air conditioning, cabin adjustment, and track adjustment.

Crawler Excavators New Holland E215C EVO

Technical specs - E215C EVO New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.7 t
Transport length
9.4 m
Transport width
2.99 m
Transport height
2.97 m
Bucket capacity
1.2 m³
Bucket capacity max.
1.2 m³
Undercarriage
SL
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.9 m
Dredging depth
6.65 m
Tear-out force
188 kN
Engine manuf.
FPT
Engine type
NEF6
Engine power
116.9 kW
Displacement
6.73 l
Revolutions at max torque
1600 rpm
Max. torque
556.3 Nm
No. of cylinders
6
Cylinder bore x stroke
104 x 132 mm
Emission level
Tier 3

More technical details, like: bucket capacity min., bucket width, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E215C EVO FAQ

When was the New Holland E215C EVO manufactured?

The New Holland E215C EVO was first produced in 2022.

How much does the New Holland E215C EVO weigh?

The New Holland E215C EVO weighs 22.7 tons.

What are the transport dimensions of the New Holland E215C EVO?

The New Holland E215C EVO has a transport length of 9.4 meters, a transport width of 2.99 meters, and a transport height of 2.97 meters.

What are the undercarriage specifications of the New Holland E215C EVO?

The New Holland E215C EVO has a standard undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the New Holland E215C EVO?

The New Holland E215C EVO has a dredging depth of 6.65 meters, a maximum horizontal reach of 9.9 meters, and is equipped with a monobloc boom.

What is the power rating of the New Holland E215C EVO?

The source data does not provide the power rating for the New Holland E215C EVO.

What is the bucket capacity of the New Holland E215C EVO's primary work tool?

The bucket capacity of the New Holland E215C EVO's primary work tool is 1.2 cubic meters.

How much is a New Holland E215C EVO Crawler excavator (2022u20132025) worth?

The residual value of the New Holland E215C EVO depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
