E 195 LC New Holland excavator specs & Dimensions (2006 - 2011)

New Holland E 195 LC is a crawler excavator manufactured from 2006 to 2011, with a weight of 19.5 tons. It features a track width …

New Holland E 195 LC is a crawler excavator manufactured from 2006 to 2011, with a weight of 19.5 tons. It features a track width of 600 mm, a transport length of 8.88 meters, and a transport width of 3.03 meters. The excavator is equipped with a bucket capacity of 1 cubic meter and includes special equipment such as a hydraulic quick hitch.

Crawler Excavators New Holland E 195 LC

Technical specs - E 195 LC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.5 t
Transport length
8.88 m
Transport width
3.03 m
Bucket capacity
1 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Model series
E
Engine manuf.
CNH
Engine type
445TA-MLF
Engine power
93 kW
Displacement
4.5 l
Revolutions at max torque
2200 rpm

More technical details, like: transport height, bucket capacity min., bucket capacity max., max. reach horizontal, dredging depth, tear-out force, bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E 195 LC FAQ

When was the New Holland E 195 LC manufactured?

The New Holland E 195 LC was manufactured from 2006 to 2011.

How much does the New Holland E 195 LC weigh?

The New Holland E 195 LC weighs 19.5 tons.

What are the transport dimensions of the New Holland E 195 LC?

The New Holland E 195 LC has a transport length of 8.88 meters and a transport width of 3.03 meters.

What are the undercarriage specifications of the New Holland E 195 LC?

The New Holland E 195 LC has a long undercarriage with a track width of 600 mm.

What type of boom does the New Holland E 195 LC have?

The New Holland E 195 LC has a monobloc boom.

What is the bucket capacity of the New Holland E 195 LC excavator?

The bucket capacity of the New Holland E 195 LC excavator is 1 cubic meter.

How much is a New Holland E 195 LC Crawler excavator (2006u20132011) worth?

The residual value of the New Holland E 195 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
