10MCR Mecalac excavator specs & Dimensions (2021 - 2026)

Mecalac 10MCR is a Crawler Excavator manufactured since 2021. It has a weight of 9.4 tons and a track width of 400 mm. The transpo…

Mecalac 10MCR is a Crawler Excavator manufactured since 2021. It has a weight of 9.4 tons and a track width of 400 mm. The transport dimensions are 3.344 meters in length, 2.3 meters in width, and 2.836 meters in height. The excavator features a tear-out force of 34 kN, a dredging depth of 4 meters, and a maximum horizontal reach of 7.5 meters. It comes with a bucket capacity of 0.36 cubic meters and includes special equipment such as a blade and a hydraulic quick hitch.

Crawler Excavators Mecalac 10MCR

Technical specs - 10MCR Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.4 t
Transport length
3.344 m
Transport width
2.3 m
Transport height
2.836 m
Bucket capacity
0.36 m³
Undercarriage
SL
Track width
400 mm
Boom
VA/SKA
Max. Reach horizontal
7.5 m
Dredging depth
4 m
Tear-out force
34 kN
Bucket width
0.8 m
Model series
MCR
Engine manuf.
Deutz
Engine type
TCD3.6 L4
Engine power
55.4 kW
Displacement
3.6 l
Revolutions at max torque
2200 rpm
Max. torque
405/1300 Nm
No. of cylinders
4
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Mecalac 10MCR FAQ

When was the Mecalac 10MCR manufactured?

The Mecalac 10MCR was first produced in 2021.

How much does the Mecalac 10MCR weigh?

The Mecalac 10MCR weighs 9.4 tons.

What are the transport dimensions of the Mecalac 10MCR crawler excavator?

The Mecalac 10MCR has a transport length of 3.34 meters, a transport width of 2.3 meters, and a transport height of 2.84 meters.

What are the undercarriage specifications of the Mecalac 10MCR?

The Mecalac 10MCR has a standard undercarriage with a track width of 400 mm.

What are the excavation performance specifications of the Mecalac 10MCR crawler excavator?

The Mecalac 10MCR has a dredging depth of 4 meters, a maximum horizontal reach of 7.5 meters, and features a lateral articulated and adjustable boom.

What is the tear-out force of the Mecalac 10MCR?

The Mecalac 10MCR has a tear-out force of 34 kN.

What are the specifications of the primary work tool on the Mecalac 10MCR?

The primary work tool of the Mecalac 10MCR has a bucket capacity of 0.36 cubic meters and a bucket width of 0.8 meters.

How much is a Mecalac 10MCR Crawler excavator (2021u20132025) worth?

The residual value of the Mecalac 10MCR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
