CDM6365H Lonking excavator specs & Dimensions (2017 - 2026)

Lonking CDM6365H is a Crawler Excavator manufactured since 2017. It has a weight of 34 tons and a track width of 600 mm. The trans…

Lonking CDM6365H is a Crawler Excavator manufactured since 2017. It has a weight of 34 tons and a track width of 600 mm. The transport dimensions are 11.283 meters in length, 3.19 meters in width, and 3.518 meters in height. The dredging depth is 7.069 meters, with a bucket width of 1.46 meters and a bucket capacity of 1.6 cubic meters.

Crawler Excavators Lonking CDM6365H

Technical specs - CDM6365H Lonking

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
34 t
Transport length
11.283 m
Transport width
3.19 m
Transport height
3.518 m
Bucket capacity
1.6 m³
Track width
600 mm
Dredging depth
7.069 m
Bucket width
1.46 m
Model series
CDM
Engine manuf.
Cummins
Engine type
6CTAA8.3-C
Engine power
197 kW
Displacement
8.3 l
Revolutions at max torque
1950 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, max. reach horizontal, tear-out force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Lonking CDM6365H FAQ

When was the Lonking CDM6365H manufactured?

The Lonking CDM6365H was first produced in 2017.

How much does the Lonking CDM6365H weigh?

The Lonking CDM6365H weighs 34 tons.

What are the transport dimensions of the Lonking CDM6365H crawler excavator?

The Lonking CDM6365H has a transport length of 11.28 meters, a transport width of 3.19 meters, and a transport height of 3.52 meters.

What is the track width of the Lonking CDM6365H's undercarriage?

The Lonking CDM6365H has a track width of 600 mm.

What is the dredging depth capability of the Lonking CDM6365H?

The Lonking CDM6365H has a dredging depth of 7.069 meters.

What are the bucket specifications of the Lonking CDM6365H crawler excavator?

The Lonking CDM6365H has a bucket capacity of 1.6 cubic meters and a bucket width of 1.46 meters.

How much is a Lonking CDM6365H Crawler excavator (2017u20132025) worth?

The residual value of the Lonking CDM6365H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
