LS-1600 Link-Belt excavator specs & Dimensions (1987 - 1991)

Link-Belt LS-1600 is a crawler excavator manufactured from 1987 to 1991, with a weight of 6.6 tons. It features a track width of 4…

Link-Belt LS-1600 is a crawler excavator manufactured from 1987 to 1991, with a weight of 6.6 tons. It features a track width of 480 mm and has transport dimensions of 5 meters in length, 2 meters in width, and 2 meters in height. The excavator is equipped with air conditioning and track adjustment.

Crawler Excavators Link-Belt LS-1600

Technical specs - LS-1600 Link-Belt

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.6 t
Transport length
5 m
Transport width
2 m
Transport height
2 m
Undercarriage
SL
Track width
480 mm
Boom
MB
Max. Reach horizontal
6.98 m
Dredging depth
4.81 m
Bucket width
0.73 m
Engine manuf.
Isuzu
Engine type
4BB1
Engine power
45 kW
Displacement
3595 l
Revolutions at max torque
1600 rpm
Max. torque
212 Nm
No. of cylinders
4
Cylinder bore x stroke
102 x 110 mm

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., tear-out force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Link-Belt LS-1600 FAQ

When was the Link-Belt LS-1600 manufactured?

The Link-Belt LS-1600 was manufactured from 1987 to 1991.

How much does the Link-Belt LS-1600 weigh?

The Link-Belt LS-1600 weighs 6.6 tons.

What are the transport dimensions of the Link-Belt LS-1600 crawler excavator?

The Link-Belt LS-1600 has transport dimensions of 5 meters in length, 2 meters in width, and 2 meters in height.

What are the undercarriage specifications of the Link-Belt LS-1600?

The Link-Belt LS-1600 has a standard undercarriage with a track width of 480 mm.

What are the excavation performance specifications of the Link-Belt LS-1600?

The Link-Belt LS-1600 has a dredging depth of 4.81 meters, a maximum horizontal reach of 6.98 meters, and is equipped with a monobloc boom.

What is the bucket width of the Link-Belt LS-1600 crawler excavator?

The bucket width of the Link-Belt LS-1600 is 0.73 meters.

How much is a Link-Belt LS-1600 Crawler excavator (1987u20131991) worth?

The residual value of the Link-Belt LS-1600 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
