160 X2 Link-Belt excavator specs & Dimensions (2017 - 2023)

Link-Belt 160 X2 is a crawler excavator manufactured since 2017, with a weight of 17.1 tons. It features a track width of 600 mm, …

Link-Belt 160 X2 is a crawler excavator manufactured since 2017, with a weight of 17.1 tons. It features a track width of 600 mm, a transport length of 8.44 meters, a transport width of 2.59 meters, and a transport height of 3.02 meters. The machine has a dredging depth of 6.06 meters and a maximum horizontal reach of 8.87 meters, with a bucket capacity of 0.87 cubic meters.

Crawler Excavators Link-Belt 160 X2

Technical specs - 160 X2 Link-Belt

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.1 t
Transport length
8.44 m
Transport width
2.59 m
Transport height
3.02 m
Bucket capacity
0.87 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.87 m
Dredging depth
6.06 m
Model series
X2
Engine manuf.
Isuzu
Engine type
AI-4JJ1X
Engine power
89 kW
Displacement
3 l
Revolutions at max torque
1800 rpm
Max. torque
391 Nm
No. of cylinders
4
Emission level
Tier 3

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, tear-out force, bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Link-Belt 160 X2 FAQ

When was the Link-Belt 160 X2 manufactured?

The Link-Belt 160 X2 was manufactured from 2017 to 2023.

How much does the Link-Belt 160 X2 weigh?

The Link-Belt 160 X2 weighs 17.1 tons.

What are the transport dimensions of the Link-Belt 160 X2 crawler excavator?

The Link-Belt 160 X2 has a transport length of 8.44 meters, a transport width of 2.59 meters, and a transport height of 3.02 meters.

What is the track width of the Link-Belt 160 X2 crawler excavator?

The Link-Belt 160 X2 crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the Link-Belt 160 X2 crawler excavator?

The Link-Belt 160 X2 crawler excavator has a dredging depth of 6.06 meters, a maximum horizontal reach of 8.87 meters, and features a monobloc boom.

What is the bucket capacity of the Link-Belt 160 X2 excavator?

The bucket capacity of the Link-Belt 160 X2 excavator is 0.87 cubic meters.

How much is a Link-Belt 160 X2 Crawler excavator (2017u20132023) worth?

The residual value of the Link-Belt 160 X2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
