130 X3 Link-Belt excavator specs & Dimensions (2012 - 2023)

Link-Belt 130 X3 is a Crawler Excavator manufactured since 2012. It has a weight of 13 tons and a track width of 600 mm. The trans…

Link-Belt 130 X3 is a Crawler Excavator manufactured since 2012. It has a weight of 13 tons and a track width of 600 mm. The transport dimensions are 7 meters in length, 2 meters in width, and 2 meters in height. The excavator features a tear-out force of 95 kN and a bucket width of 1.676 meters. Special equipment includes air conditioning, a blade, a diesel particulate filter, and track adjustment.

Crawler Excavators Link-Belt 130 X3

Technical specs - 130 X3 Link-Belt

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13 t
Transport length
7 m
Transport width
2 m
Transport height
2 m
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.77 m
Dredging depth
6.05 m
Tear-out force
95 kN
Bucket width
1.676 m
Engine manuf.
Isuzu
Engine type
AM-4JJ1X
Engine power
75 kW
Displacement
3 l
Revolutions at max torque
1600 rpm
Max. torque
359 Nm
No. of cylinders
4
Emission level
Tier 4A

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Link-Belt 130 X3 FAQ

When was the Link-Belt 130 X3 manufactured?

The Link-Belt 130 X3 was manufactured from 2012 to 2023.

How much does the Link-Belt 130 X3 weigh?

The Link-Belt 130 X3 weighs 13 tons.

What are the transport dimensions of the Link-Belt 130 X3 crawler excavator?

The Link-Belt 130 X3 has a transport length of 7 meters, a transport width of 2 meters, and a transport height of 2 meters.

What are the undercarriage specifications of the Link-Belt 130 X3?

The Link-Belt 130 X3 has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Link-Belt 130 X3 crawler excavator?

The Link-Belt 130 X3 crawler excavator has a dredging depth of 6.05 meters, a maximum horizontal reach of 8.77 meters, and is equipped with a Monobloc boom.

What is the tear-out force of the Link-Belt 130 X3?

The Link-Belt 130 X3 has a tear-out force of 95 kN.

What is the bucket width of the Link-Belt 130 X3 excavator?

The bucket width of the Link-Belt 130 X3 excavator is 1.676 meters.
