R 994B Liebherr excavator specs & Dimensions (2002 - 2020)

Liebherr R994B is a Crawler Excavator manufactured since 2002, with a weight of 309.4 tons. It features a track width of 850 mm, a…

Liebherr R994B is a Crawler Excavator manufactured since 2002, with a weight of 309.4 tons. It features a track width of 850 mm, a transport length of 10.47 meters, a transport width of 7.19 meters, and a transport height of 7.57 meters. The machine has a tear-out force of 880 kN, a dredging depth of 9.5 meters, and a maximum horizontal reach of 16.3 meters. The bucket width is 3.4 meters, and the bucket capacity is 18 cubic meters.

Crawler Excavators Liebherr R 994B

Visit Liebherr live at

Technical specs - R 994B Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
309.4 t
Transport length
10.47 m
Transport width
7.19 m
Transport height
7.57 m
Bucket capacity
18 m³
Track width
850 mm
Max. Reach horizontal
16.3 m
Dredging depth
9.5 m
Tear-out force
880 kN
Bucket width
3.4 m
Model series
R
Engine manuf.
Cummins
Engine type
QSK45
Engine power
1120 kW
Displacement
45 l
Revolutions at max torque
1800 rpm
No. of cylinders
12
Cylinder bore x stroke
159x190 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 994B FAQ

When was the Liebherr R994B manufactured?

The Liebherr R994B was first produced in 2002.

How much does the Liebherr R994B weigh?

The Liebherr R994B weighs 309.4 tons.

What are the transport dimensions of the Liebherr R994B crawler excavator?

The Liebherr R994B crawler excavator has a transport length of 10.47 meters, a transport width of 7.19 meters, and a transport height of 7.57 meters.

What is the track width of the Liebherr R994B's undercarriage?

The Liebherr R994B has a track width of 850 mm.

What is the excavation performance of the Liebherr R994B crawler excavator?

The Liebherr R994B crawler excavator has a dredging depth of 9.5 meters and a maximum horizontal reach of 16.3 meters.

What is the tear-out force of the Liebherr R994B?

The Liebherr R994B has a tear-out force of 880 kN.

What are the specifications of the primary work tool on the Liebherr R994B?

The primary work tool of the Liebherr R994B has a bucket capacity of 18 cubic meters and a bucket width of 3.4 meters.

How much is a Liebherr R994B Crawler excavator (2002u20132025) worth?

The residual value of the Liebherr R994B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
