R 938 Litronic Liebherr excavator specs & Dimensions (2019 - 2026)

Liebherr R 938 Litronic is a Crawler Excavator manufactured since 2019. It has a weight of 38.65 tons and a track width of 600 mm.…

Liebherr R 938 Litronic is a Crawler Excavator manufactured since 2019. It has a weight of 38.65 tons and a track width of 600 mm. The transport dimensions are 11.45 meters in length, 2.99 meters in width, and 3.15 meters in height. The machine features a tear-out force of 238 kN, a dredging depth of 8.23 meters, and a maximum horizontal reach of 12.4 meters. The bucket capacity is 3 cubic meters. Special equipment includes air conditioning and an overload alert system.

Crawler Excavators Liebherr R 938 Litronic
Crawler Excavators Liebherr R 938 Litronic
Crawler Excavators Liebherr R 938 Litronic
Crawler Excavators Liebherr R 938 Litronic

Visit Liebherr live at

Technical specs - R 938 Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
38.65 t
Transport length
11.45 m
Transport width
2.99 m
Transport height
3.15 m
Bucket capacity
3 m³
Undercarriage
LC/NLC
Track width
600 mm
Boom
VA
Max. Reach horizontal
12.4 m
Dredging depth
8.23 m
Tear-out force
238 kN
Model series
R
Engine manuf.
Liebherr
Engine type
D944 A7-25
Engine power
220 kW
Displacement
8 l
Revolutions at max torque
1800 rpm
No. of cylinders
4
Cylinder bore x stroke
130x150 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 938 Litronic FAQ

When was the Liebherr R 938 Litronic manufactured?

The Liebherr R 938 Litronic was first produced in 2019.

How much does the Liebherr R 938 Litronic weigh?

The Liebherr R 938 Litronic weighs 38.65 tons.

What are the transport dimensions of the Liebherr R 938 Litronic?

The Liebherr R 938 Litronic has a transport length of 11.45 meters, a transport width of 2.99 meters, and a transport height of 3.15 meters.

What are the undercarriage specifications of the Liebherr R 938 Litronic?

The Liebherr R 938 Litronic has a long, small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 938 Litronic?

The Liebherr R 938 Litronic has a dredging depth of 8.23 meters, a maximum horizontal reach of 12.4 meters, and features an adjustable boom.

What is the tear-out force of the Liebherr R 938 Litronic?

The Liebherr R 938 Litronic has a tear-out force of 238 kN.

What is the bucket capacity of the Liebherr R 938 Litronic?

The Liebherr R 938 Litronic has a bucket capacity of 3 cubic meters.

How much is a Liebherr R 938 Litronic Crawler excavator (2019u20132025) worth?

The residual value of the Liebherr R 938 Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Liebherr R 938 Litronic overview

Engine

Wide Product Range

The Liebherr Group is one of the largest construction equipment manufacturers in the world. Liebherr’s high-value products and services enjoy a high reputation in many other fields. The wide range includes domestic appliances, aerospace and transportation systems, machine tools and maritime cranes.


Exceptional Customer Benefit

Every product line provides a complete range of models in many different versions. With both their technical excellence and acknowledged quality, Liebherr products offer a maximum of customer benefits in practical applications.


Hydraulic and electronic system

Maintenance

Innovative servicing concept, with service points accessible from ground levelEngine oil, hydraulic oil, fuel and urea (diesel exhaust fluid) levels visible on the displayNew concept for lateral access to undercarriage and large maintenance platform


Undercarriage

Undercarriage

Choice of 3 different robust x-shaped undercarriages with integrated eyes for secure transportEasy maintenanceMaintenance-free track chains and track rollers with lifetime lubricationExtra storage (option)


Cab

Safety

Panoramic visibility with no obstructions and camera on the rear and the right side for enhanced safetyTiltable console for easy and safe access to cabROPS-certified cab structureEmergency exit via the rear cab windowRight window and windshield in laminated and tinted glass


Comfort

Spacious, air-conditioned work spaceAirsprung seat with vertical and longitudinal suspensionEasy-to-use high resolution 7” colour touchscreenCompletely retractable front cab windowNew LED lighting as standard


Equipment

Equipment

Large choice of types and lengths of equipmentSafety check valves for hoist and stick cylinders (option)Longer lifespan of components and higher productivity thanks to automatic centralised lubrication system
