R 936 Compact Litronic Liebherr excavator specs & Dimensions (2019 - 2026)

Liebherr R 936 Compact Litronic is a crawler excavator manufactured since 2019. It has a weight of 36.95 tons and a track width of…

Liebherr R 936 Compact Litronic is a crawler excavator manufactured since 2019. It has a weight of 36.95 tons and a track width of 600 mm. The transport dimensions are 10.95 meters in length, 3 meters in width, and 3.2 meters in height. The machine features a tear-out force of 204 kN, a dredging depth of 8 meters, and a maximum horizontal reach of 11.74 meters. The bucket capacity is 2.15 cubic meters. Special equipment includes air conditioning, a blade, material handling capabilities, and an overload alert system.

Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic
Crawler Excavators Liebherr R 936 Compact Litronic

Visit Liebherr live at

Technical specs - R 936 Compact Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.95 t
Transport length
10.95 m
Transport width
3 m
Transport height
3.2 m
Bucket capacity
2.15 m³
Undercarriage
LC/NLC/SL
Track width
600 mm
Max. Reach horizontal
11.74 m
Dredging depth
8 m
Tear-out force
204 kN
Model series
R
Engine manuf.
Liebherr
Engine type
D944 A7-25
Engine power
190 kW
Displacement
8 l
Revolutions at max torque
1800 rpm
No. of cylinders
4
Cylinder bore x stroke
130x150 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., boom, bucket width, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 936 Compact Litronic FAQ

When was the Liebherr R 936 Compact Litronic manufactured?

The Liebherr R 936 Compact Litronic was first produced in 2019.

How much does the Liebherr R 936 Compact Litronic weigh?

The Liebherr R 936 Compact Litronic weighs 36.95 tons.

What are the transport dimensions of the Liebherr R 936 Compact Litronic?

The Liebherr R 936 Compact Litronic has a transport length of 10.95 meters, a transport width of 3 meters, and a transport height of 3.2 meters.

What are the undercarriage specifications of the Liebherr R 936 Compact Litronic?

The Liebherr R 936 Compact Litronic has an undercarriage described as Long, Small, Standard with a track width of 600 mm.

What are the excavation capabilities of the Liebherr R 936 Compact Litronic?

The Liebherr R 936 Compact Litronic has a dredging depth of 8 meters and a maximum horizontal reach of 11.74 meters.

What are the power ratings of the Liebherr R 936 Compact Litronic?

The available data does not provide power ratings for the Liebherr R 936 Compact Litronic.

What is the bucket capacity of the Liebherr R 936 Compact Litronic?

The bucket capacity of the Liebherr R 936 Compact Litronic is 2.15 cubic meters.

How much is a Liebherr R 936 Compact Litronic Crawler excavator (2019u20132025) worth?

The residual value of the Liebherr R 936 Compact Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
