R 926 Compact Litronic Liebherr excavator specs & Dimensions (2019 - 2021)

Liebherr R 926 Compact Litronic is a crawler excavator manufactured from 2019 to 2021. It has a weight of 28.25 tons and a track w…

Liebherr R 926 Compact Litronic is a crawler excavator manufactured from 2019 to 2021. It has a weight of 28.25 tons and a track width of 600 mm. The transport dimensions are 9.35 meters in length, 2.92 meters in width, and 3.415 meters in height. The machine features a tear-out force of 102 kN, a dredging depth of 7.1 meters, and a maximum horizontal reach of 10.05 meters. The bucket capacity is 1.5 cubic meters. Special equipment includes air conditioning, a blade, material handling capabilities, and an overload alert system.

Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic

Visit Liebherr live at

Technical specs - R 926 Compact Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
28.25 t
Transport length
9.35 m
Transport width
2.92 m
Transport height
3.415 m
Bucket capacity
1.5 m³
Undercarriage
LC
Track width
600 mm
Boom
UA
Max. Reach horizontal
10.05 m
Dredging depth
7.1 m
Tear-out force
102 kN
Model series
R
Engine manuf.
Liebherr
Engine type
D924 A7-04
Engine power
129 kW
Displacement
4.5 l
Revolutions at max torque
1900 rpm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
IV

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 926 Compact Litronic FAQ

When was the Liebherr R 926 Compact Litronic manufactured?

The Liebherr R 926 Compact Litronic was manufactured from 2019 to 2021.

How much does the Liebherr R 926 Compact Litronic weigh?

The Liebherr R 926 Compact Litronic weighs 28.25 tons.

What are the transport dimensions of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a transport length of 9.35 meters, a transport width of 2.92 meters, and a transport height of 3.42 meters.

What are the undercarriage specifications of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a dredging depth of 7.1 meters, a maximum horizontal reach of 10.05 meters, and is equipped with a material handling boom.

What is the tear-out force of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a tear-out force of 102 kN.

What is the bucket capacity of the Liebherr R 926 Compact Litronic?

The bucket capacity of the Liebherr R 926 Compact Litronic is 1.5 cubic meters.

How much is a Liebherr R 926 Compact Litronic Crawler excavator (2019u20132021) worth?

The residual value of the Liebherr R 926 Compact Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
