R 313 Litronic Liebherr excavator specs & Dimensions (2006 - 2011)

Model rating
6,00 / 10

Liebherr R 313 Litronic is a crawler excavator manufactured from 2006 to 2011, with a weight of 14.9 tons. It has a track width of…

Liebherr R 313 Litronic is a crawler excavator manufactured from 2006 to 2011, with a weight of 14.9 tons. It has a track width of 600 mm, a transport length of 8 meters, a transport width of 2.6 meters, and a transport height of 2.91 meters.

Crawler Excavators Liebherr R 313 Litronic

Visit Liebherr live at

Technical specs - R 313 Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.9 t
Transport length
8 m
Transport width
2.6 m
Transport height
2.91 m
Bucket capacity
0.5 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.2 m
Dredging depth
5.5 m
Tear-out force
67.9 kN
Bucket width
0.85 m
Model series
R
Engine manuf.
Deutz
Engine type
BF4M2012C
Engine power
76 kW
Displacement
4.038 l
Revolutions at max torque
1800 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 313 Litronic FAQ

When was the Liebherr R 313 Litronic manufactured?

The Liebherr R 313 Litronic was manufactured from 2006 to 2011.

How much does the Liebherr R 313 Litronic weigh?

The Liebherr R 313 Litronic weighs 14.9 tons.

What are the transport dimensions of the Liebherr R 313 Litronic crawler excavator?

The Liebherr R 313 Litronic has a transport length of 8 meters, a transport width of 2.6 meters, and a transport height of 2.91 meters.

What is the track width of the Liebherr R 313 Litronic's undercarriage?

The Liebherr R 313 Litronic has a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 313 Litronic?

The Liebherr R 313 Litronic has a dredging depth of 5.5 meters, a maximum horizontal reach of 8.2 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Liebherr R 313 Litronic?

The Liebherr R 313 Litronic has a tear-out force of 67.9 kN.

What are the specifications of the bucket on the Liebherr R 313 Litronic?

The bucket of the Liebherr R 313 Litronic has a capacity of 0.5 cubic meters and a width of 0.85 meters.

How much is a Liebherr R 313 Litronic Crawler excavator (2006u20132011) worth?

The residual value of the Liebherr R 313 Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating
6,00 / 10
Quotation mark

Liebherr R 313 Litronic user from

Poor back up, expensive spares
