984 Liebherr excavator specs & Dimensions (1988 - 2020)

Liebherr 984 is a Crawler Excavator manufactured since 1988. It has a weight of 94.1 tons and a track width of 750 mm. The transpo…

Liebherr 984 is a Crawler Excavator manufactured since 1988. It has a weight of 94.1 tons and a track width of 750 mm. The transport dimensions are 7.035 meters in length, 5.09 meters in width, and 4.5 meters in height. The machine features a tear-out force of 345 kN, a dredging depth of 8.6 meters, and a maximum horizontal reach of 14.1 meters. The bucket width is 2.53 meters, with a capacity of 8 cubic meters.

Crawler Excavators Liebherr 984

Visit Liebherr live at

Technical specs - 984 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
94.1 t
Transport length
7.035 m
Transport width
5.09 m
Transport height
4.5 m
Bucket capacity
8 m³
Track width
750 mm
Max. Reach horizontal
14.1 m
Dredging depth
8.6 m
Tear-out force
345 kN
Bucket width
2.53 m
Engine manuf.
Cummins
Engine type
KTA19C525
Engine power
392 kW
Displacement
18.9 l
Revolutions at max torque
2100 rpm
No. of cylinders
6
Cylinder bore x stroke
159x159 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, model series, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Liebherr 984 FAQ

When was the Liebherr 984 manufactured?

The Liebherr 984 was first produced in 1988.

How much does the Liebherr 984 crawler excavator weigh?

The Liebherr 984 crawler excavator weighs 94.1 tons.

What are the transport dimensions of the Liebherr 984 crawler excavator?

The Liebherr 984 crawler excavator has a transport length of 7.04 meters, a transport width of 5.09 meters, and a transport height of 4.5 meters.

What is the track width of the Liebherr 984 crawler excavator?

The Liebherr 984 crawler excavator has a track width of 750 mm.

What are the dredging depth and maximum horizontal reach of the Liebherr 984?

The Liebherr 984 has a dredging depth of 8.6 meters and a maximum horizontal reach of 14.1 meters.

What are the power ratings of the Liebherr 984 crawler excavator?

The available data does not provide power ratings for the Liebherr 984 crawler excavator.

What are the specifications of the primary work tool bucket on the Liebherr 984?

The primary work tool bucket of the Liebherr 984 has a capacity of 8 cubic meters and a width of 2.53 meters.
