RH40E Bucyrus excavator specs & Dimensions (2010 - 2011)

Bucyrus RH40E is a crawler excavator manufactured from 2010 to 2011. It has a weight of 108.35 tons and a track width of 900 mm. T…

Bucyrus RH40E is a crawler excavator manufactured from 2010 to 2011. It has a weight of 108.35 tons and a track width of 900 mm. The transport width is 5.34 meters. The excavator features a tear-out force of 64 kN, a dredging depth of 2 meters, and a maximum horizontal reach of 11 meters. The bucket width is 3 meters, with a capacity ranging from 6 m³ to 8.1 m³. Special equipment includes air conditioning and a diesel particulate filter.

Crawler Excavators Bucyrus RH40E

Technical specs - RH40E Bucyrus

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
108.35 t
Transport width
5.34 m
Bucket capacity min.
6 m³
Bucket capacity max.
8.1 m³
Track width
900 mm
Max. Reach horizontal
11 m
Dredging depth
2.2 m
Tear-out force
64.72 kN
Bucket width
3 m
Engine manuf.
Caterpillar
Engine type
C18
Engine power
522 kW
Displacement
18.1 l
Revolutions at max torque
1800 rpm
No. of cylinders
6
Cylinder bore x stroke
145 x 183 mm
Emission level
Tier 3/Stage III A

More technical details, like: transport length, transport height, bucket capacity, undercarriage, boom, model series, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Bucyrus RH40E FAQ

When was the Bucyrus RH40E manufactured?

The Bucyrus RH40E was manufactured from 2010 to 2011.

How much does the Bucyrus RH40E weigh?

The Bucyrus RH40E weighs 108.35 tons.

What is the transport width of the Bucyrus RH40E?

The transport width of the Bucyrus RH40E is 5.34 meters.

What is the track width of the Bucyrus RH40E's undercarriage?

The Bucyrus RH40E has a track width of 900 mm.

What are the excavation performance specifications of the Bucyrus RH40E?

The Bucyrus RH40E has a dredging depth of 2.2 meters and a maximum horizontal reach of 11 meters.

What is the tear-out force of the Bucyrus RH40E?

The Bucyrus RH40E has a tear-out force of 64.72 kN.

What are the bucket specifications of the Bucyrus RH40E crawler excavator?

The Bucyrus RH40E has a bucket with a maximum capacity of 8.1 cubic meters, a minimum capacity of 6 cubic meters, and a width of 3 meters.
