SK 210 LC 10 Kobelco excavator specs & Dimensions (2015 - 2019)

Kobelco SK 210 LC 10 is a Crawler Excavator manufactured from 2015 to 2019. It has a weight of 23.3 tons and a track width of 600 …

Kobelco SK 210 LC 10 is a Crawler Excavator manufactured from 2015 to 2019. It has a weight of 23.3 tons and a track width of 600 mm. The transport dimensions are 12.64 meters in length, 2.99 meters in width, and 3.1 meters in height. The machine features a dredging depth of 12.01 meters and a maximum horizontal reach of 15.82 meters. The bucket width is 0.8 meters with a capacity of 0.45 cubic meters. Special equipment includes air conditioning, a diesel particulate filter, an overload alert, and a hydraulic quick hitch.

Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10
Crawler Excavators Kobelco SK 210 LC 10

Visit Kobelco live at

Technical specs - SK 210 LC 10 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.3 t
Transport length
12.64 m
Transport width
2.99 m
Transport height
3.1 m
Bucket capacity
0.45 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
15.82 m
Dredging depth
12.01 m
Bucket width
0.8 m
Engine manuf.
Hino
Engine type
J 05 EUM-KSSC
Engine power
124 kW
Displacement
5.123 l
Revolutions at max torque
1600 rpm
Max. torque
660 Nm
No. of cylinders
4
Cylinder bore x stroke
112x130 mm
Emission level
Tier 4 Final

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 210 LC 10 FAQ

When was the Kobelco SK 210 LC 10 manufactured?

The Kobelco SK 210 LC 10 was manufactured from 2015 to 2019.

How much does the Kobelco SK 210 LC 10 weigh?

The Kobelco SK 210 LC 10 weighs 23.3 tons.

What are the transport dimensions of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a transport length of 12.64 meters, a transport width of 2.99 meters, and a transport height of 3.1 meters.

What are the undercarriage specifications of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a dredging depth of 12.01 meters, a maximum horizontal reach of 15.82 meters, and is equipped with a monobloc boom.

What are the specifications of the primary work tool on the Kobelco SK 210 LC 10?

The primary work tool of the Kobelco SK 210 LC 10 has a bucket capacity of 0.45 cubic meters and a bucket width of 0.8 meters.

How much is a Kobelco SK 210 LC 10 Crawler excavator (2015u20132019) worth?

The residual value of the Kobelco SK 210 LC 10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
