SK 210 D 10 CD Kobelco excavator specs & Dimensions (2017 - 2019)

Kobelco SK 210 D 10 CD is a Crawler Excavator manufactured from 2017 to 2019. It has a weight of 27 tons and a track width of 600 …

Kobelco SK 210 D 10 CD is a Crawler Excavator manufactured from 2017 to 2019. It has a weight of 27 tons and a track width of 600 mm. The transport dimensions are 12.21 meters in length, 2.8 meters in width, and 3.72 meters in height. The excavator features a tear-out force of 882 kN, a dredging depth of 7.79 meters, and a maximum horizontal reach of 11.07 meters. It is equipped with air conditioning, a diesel particulate filter, an overload alert system, and a hydraulic quick hitch.

Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD
Crawler Excavators Kobelco SK 210 D 10 CD

Visit Kobelco live at

Technical specs - SK 210 D 10 CD Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
27 t
Transport length
12.21 m
Transport width
2.8 m
Transport height
3.72 m
Undercarriage
NLC
Track width
600 mm
Boom
MB
Max. Reach horizontal
11.07 m
Dredging depth
7.79 m
Tear-out force
882 kN
Engine manuf.
Hino
Engine type
J 05 EUM-KSSC
Engine power
124 kW
Displacement
5.123 l
Revolutions at max torque
1600 rpm
Max. torque
660 Nm
No. of cylinders
4
Cylinder bore x stroke
112x130 mm
Emission level
Tier 4 Final

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 210 D 10 CD FAQ

When was the Kobelco SK 210 D 10 CD manufactured?

The Kobelco SK 210 D 10 CD was manufactured from 2017 to 2019.

How much does the Kobelco SK 210 D 10 CD weigh?

The Kobelco SK 210 D 10 CD weighs 27 tons.

What are the transport dimensions of the Kobelco SK 210 D 10 CD?

The Kobelco SK 210 D 10 CD has a transport length of 12.21 meters, a transport width of 2.8 meters, and a transport height of 3.72 meters.

What are the undercarriage specifications of the Kobelco SK 210 D 10 CD?

The Kobelco SK 210 D 10 CD has a small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Kobelco SK 210 D 10 CD?

The Kobelco SK 210 D 10 CD has a dredging depth of 7.79 meters, a maximum horizontal reach of 11.07 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Kobelco SK 210 D 10 CD?

The Kobelco SK 210 D 10 CD has a tear-out force of 882 kN.

How much is a Kobelco SK 210 D 10 CD Crawler excavator (2017u20132019) worth?

The residual value of the Kobelco SK 210 D 10 CD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
