HD513MRIII Kato excavator specs & Dimensions (2004 - 2023)

Kato HD513MRIII is a crawler excavator manufactured since 2004. It has a weight of 13 tons and a track width of 500 mm. The transp…

Kato HD513MRIII is a crawler excavator manufactured since 2004. It has a weight of 13 tons and a track width of 500 mm. The transport dimensions are 7 meters in length, 2 meters in width, and 2 meters in height. The excavator features a tear-out force of 88 kN, a dredging depth of 6 meters, and a maximum horizontal reach of 8 meters. The bucket width is 1 meter.

Crawler Excavators Kato HD513MRIII

Technical specs - HD513MRIII Kato

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.2 t
Transport length
7.37 m
Transport width
2.49 m
Transport height
2.76 m
Bucket capacity min.
0.25 m³
Bucket capacity max.
0.6 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.84 m
Dredging depth
6.09 m
Tear-out force
88 kN
Bucket width
1.18 m
Engine manuf.
Mitsubishi
Engine type
4D34-TLE21
Engine power
68 kW

More technical details, like: bucket capacity, undercarriage, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato HD513MRIII FAQ

When was the Kato HD513MRIII manufactured?

The Kato HD513MRIII was manufactured from 2004 to 2023.

How much does the Kato HD513MRIII weigh?

The Kato HD513MRIII weighs 13.2 tons.

What are the transport dimensions of the Kato HD513MRIII crawler excavator?

The Kato HD513MRIII has a transport length of 7.37 meters, a transport width of 2.49 meters, and a transport height of 2.76 meters.

What is the track width of the Kato HD513MRIII crawler excavator?

The Kato HD513MRIII crawler excavator has a track width of 500 mm.

What are the excavation performance specifications of the Kato HD513MRIII crawler excavator?

The Kato HD513MRIII crawler excavator has a dredging depth of 6.09 meters, a maximum horizontal reach of 8.84 meters, and features a monobloc boom.

What is the tear-out force of the Kato HD513MRIII?

The Kato HD513MRIII has a tear-out force of 88 kN. No power ratings are provided in the available data.

What are the specifications of the bucket on the Kato HD513MRIII crawler excavator?

The Kato HD513MRIII has a bucket with a maximum capacity of 0.6 cubic meters, a minimum capacity of 0.25 cubic meters, and a width of 1.18 meters.

How much is a Kato HD513MRIII Crawler excavator (2004u20132023) worth?

The residual value of the Kato HD513MRIII depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
