HD512-7 Kato excavator specs & Dimensions (2017 - 2023)

Kato HD512-7 is a Crawler Excavator manufactured since 2017. It has a weight of 12.9 t and a track width of 500 mm. The transport …

Kato HD512-7 is a Crawler Excavator manufactured since 2017. It has a weight of 12.9 t and a track width of 500 mm. The transport dimensions are 7.66 m in length, 2.49 m in width, and 2.82 m in height. The excavator features a tear-out force of 98 kN, a dredging depth of 5.59 m, and a maximum horizontal reach of 8.3 m. The bucket width is 0.98 m with a capacity of 0.5 m³. Special equipment includes air conditioning.

Crawler Excavators Kato HD512-7

Technical specs - HD512-7 Kato

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12.9 t
Transport length
7.66 m
Transport width
2.49 m
Transport height
2.82 m
Bucket capacity
0.5 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.3 m
Dredging depth
5.59 m
Tear-out force
98 kN
Bucket width
0.98 m
Model series
HD
Engine manuf.
Isuzu
Engine type
4JJ1X
Engine power
78.5 kW
Displacement
2.999 l
Revolutions at max torque
1800 rpm
Max. torque
375 Nm
No. of cylinders
4
Cylinder bore x stroke
95.4x104x9 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato HD512-7 FAQ

When was the Kato HD512-7 manufactured?

The Kato HD512-7 was manufactured from 2017 to 2023.

How much does the Kato HD512-7 weigh?

The Kato HD512-7 weighs 12.9 tons.

What are the transport dimensions of the Kato HD512-7 crawler excavator?

The Kato HD512-7 has a transport length of 7.66 meters, a transport width of 2.49 meters, and a transport height of 2.82 meters.

What is the track width of the Kato HD512-7's undercarriage?

The Kato HD512-7 has a track width of 500 mm.

What are the excavation performance specifications of the Kato HD512-7 crawler excavator?

The Kato HD512-7 crawler excavator has a dredging depth of 5.59 meters, a maximum horizontal reach of 8.3 meters, and features a monobloc boom.

What is the tear-out force of the Kato HD512-7?

The Kato HD512-7 has a tear-out force of 98 kN.

What are the specifications of the primary work tool bucket on the Kato HD512-7?

The Kato HD512-7 has a bucket with a capacity of 0.5 cubic meters and a width of 0.98 meters.

How much is a Kato HD512-7 Crawler excavator (2017u20132023) worth?

The residual value of the Kato HD512-7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
