600C John Deere Construction excavator specs & Dimensions (2002 - 2021)

John Deere Construction 600C is a crawler excavator manufactured from 2002 to 2021. It has a weight of 59.7 tons and a track width…

John Deere Construction 600C is a crawler excavator manufactured from 2002 to 2021. It has a weight of 59.7 tons and a track width of 700 mm. The transport length is 13 meters, and the transport height is 3.27 meters. The tear-out force is 259 kN, with a dredging depth of 7.9 meters and a maximum horizontal reach of 12.6 meters. Special equipment includes a blade and track adjustment.

Crawler Excavators John Deere Construction 600C

Technical specs - 600C John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
59.7 t
Transport length
13 m
Transport height
3.27 m
Track width
700 mm
Max. Reach horizontal
12.6 m
Dredging depth
7.9 m
Tear-out force
259 kN
Model series
C
Engine manuf.
Isuzu
Engine type
88-GWG1X
Engine power
295 kW
Displacement
15.7 l
Max. torque
1540 Nm
No. of cylinders
6

More technical details, like: transport width, bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

John Deere Construction 600C FAQ

When was the John Deere Construction 600C manufactured?

The John Deere Construction 600C was manufactured from 2002 to 2021.

How much does the John Deere Construction 600C weigh?

The John Deere Construction 600C weighs 59.7 tons.

What are the transport dimensions of the John Deere Construction 600C?

The John Deere Construction 600C has a transport length of 13 meters and a transport height of 3.27 meters.

What is the track width of the John Deere Construction 600C crawler excavator?

The John Deere Construction 600C crawler excavator has a track width of 700 mm.

What is the excavation performance of the John Deere Construction 600C?

The John Deere Construction 600C has a dredging depth of 7.9 meters and a maximum horizontal reach of 12.6 meters.

What is the tear-out force of the John Deere Construction 600C, given that no power ratings are provided?

The John Deere Construction 600C has a tear-out force of 259 kN.
