HMK 410 LCUHD Hidromek excavator specs & Dimensions (2020 - 2026)

Hidromek HMK 410 LCUHD is a Crawler Excavator manufactured since 2020, with a weight of 41.6 t. It features a track width of 600 m…

Hidromek HMK 410 LCUHD is a Crawler Excavator manufactured since 2020, with a weight of 41.6 t. It features a track width of 600 mm, a transport length of 10.94 m, a transport width of 3.5 m, and a transport height of 3.64 m. The machine has a tear-out force of 253.01 kN, a dredging depth of 6.53 m, and a maximum horizontal reach of 10.21 m. The bucket capacity is 2.5 m³. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, hydraulic and mechanical quick hitch, and track adjustment.

Crawler Excavators Hidromek HMK 410 LCUHD
Crawler Excavators Hidromek HMK 410 LCUHD
Crawler Excavators Hidromek HMK 410 LCUHD
Crawler Excavators Hidromek HMK 410 LCUHD

Visit Hidromek live at

Technical specs - HMK 410 LCUHD Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
42.2 t
Transport length
10.94 m
Transport width
3.5 m
Transport height
3.64 m
Bucket capacity
2.5 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.21 m
Dredging depth
6.53 m
Tear-out force
248 kN
Bucket width
1.77 m
Model series
HMK
Engine manuf.
Isuzu
Engine type
AH-6HK1X
Engine power
210 kW
Displacement
7.79 l
Revolutions at max torque
1900 rpm
Max. torque
1080/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
115x125 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Hidromek HMK 410 LCUHD FAQ

When was the Hidromek HMK 410 LCUHD manufactured?

The Hidromek HMK 410 LCUHD was first produced in 2020.

How much does the Hidromek HMK 410 LCUHD weigh?

The Hidromek HMK 410 LCUHD weighs 41.6 tons.

What are the transport dimensions of the Hidromek HMK 410 LCUHD?

The transport dimensions of the Hidromek HMK 410 LCUHD are 10.94 meters in length, 3.5 meters in width, and 3.64 meters in height.

What are the undercarriage specifications of the Hidromek HMK 410 LCUHD?

The Hidromek HMK 410 LCUHD has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Hidromek HMK 410 LCUHD?

The Hidromek HMK 410 LCUHD has a dredging depth of 6.53 meters, a maximum horizontal reach of 10.21 meters, and is equipped with a monobloc boom.

What are the power ratings of the Hidromek HMK 410 LCUHD?

The source data does not provide any power ratings for the Hidromek HMK 410 LCUHD.

What is the bucket capacity of the Hidromek HMK 410 LCUHD?

The Hidromek HMK 410 LCUHD has a bucket capacity of 2.5 cubic meters.

How much is a Hidromek HMK 410 LCUHD Crawler excavator (2020u20132025) worth?

The residual value of the Hidromek HMK 410 LCUHD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
