HMK 140 LC Hidromek excavator specs & Dimensions (2011 - 2026)

Hidromek HMK 140 LC is a Crawler Excavator manufactured since 2011, with a weight of 14.8 t and a track width of 500 mm. Its trans…

Hidromek HMK 140 LC is a Crawler Excavator manufactured since 2011, with a weight of 14.8 t and a track width of 500 mm. Its transport dimensions are 7.89 m in length, 2.49 m in width, and 2.83 m in height. The machine has a dredging depth of 5.36 m and a maximum horizontal reach of 8.07 m. The bucket width is 1 m. Special equipment includes air conditioning, a blade, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, a quick hitch hydraulic system, and track adjustment.

Visit Hidromek live at

HMK 140 LC

Years of manufacture: 2011—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - HMK 140 LC Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15 t

Transport length: 7.89 m

Transport width: 2.49 m

Transport height: 2.87 m

Bucket capacity: 0.6 m³

Undercarriage: LC

Track width: 500 mm

Boom: MB

Max. Reach horizontal: 8.07 m

Dredging depth: 5.36 m

Tear-out force: 98.06 kN

Bucket width: 1 m

Model series: HMK

Engine manuf.: Isuzu

Engine type: AJ-4JJ1X

Engine power: 73 kW

Displacement: 2.999 l

Revolutions at max torque: 1600 rpm

Max. torque: 385 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: Yes
Track adjustment: Yes
Blade: Yes
Cabin adjustment: Yes
Overload alert: Yes
Material Handling Excavator: Yes
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Hidromek HMK 140 LC FAQ

When was the Hidromek HMK 140 LC manufactured?

The Hidromek HMK 140 LC was first produced in 2011.

How much does the Hidromek HMK 140 LC weigh?

The Hidromek HMK 140 LC weighs 14.8 tons.

What are the transport dimensions of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a transport length of 7.89 meters, a transport width of 2.49 meters, and a transport height of 2.83 meters.

What are the undercarriage specifications of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a long undercarriage and a track width of 500 mm.

What are the excavation performance specifications of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a dredging depth of 5.36 meters, a maximum horizontal reach of 8.07 meters, and features a monobloc boom.

What is the tear-out force of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a tear-out force of 98.06 kN.

What are the bucket specifications of the Hidromek HMK 140 LC excavator?

The Hidromek HMK 140 LC has a bucket capacity of 0.6 cubic meters and a bucket width of 1 meter.

How much is a Hidromek HMK 140 LC Crawler excavator (2011u20132025) worth?

The residual value of the Hidromek HMK 140 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
