HMK 140 LC Hidromek excavator specs & Dimensions (2010 - 2011)

Hidromek HMK 140 LC is a crawler excavator manufactured from 2010 to 2011, with a weight of 14.3 tons and a track width of 500 mm.…

Hidromek HMK 140 LC is a crawler excavator manufactured from 2010 to 2011, with a weight of 14.3 tons and a track width of 500 mm. It is equipped with air conditioning, a blade, cabin adjustment, and an overload alert system.

Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC
Crawler Excavators Hidromek HMK 140 LC

Visit Hidromek live at

Technical specs - HMK 140 LC Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14.3 t
Bucket capacity
0.6 m³
Undercarriage
LC
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.2 m
Dredging depth
5.14 m
Tear-out force
7.4 kN
Bucket width
0.98 m
Model series
HMK
Engine manuf.
Mitsubishi
Engine type
4 M 50 TL
Engine power
92.5 kW
Displacement
4.9 l
Revolutions at max torque
1600 rpm

More technical details, like: transport length, transport width, transport height, bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hidromek HMK 140 LC FAQ

When was the Hidromek HMK 140 LC manufactured?

The Hidromek HMK 140 LC was manufactured from 2010 to 2011.

How much does the Hidromek HMK 140 LC weigh?

The Hidromek HMK 140 LC weighs 14.3 tons.

What are the undercarriage specifications of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a long undercarriage and a track width of 500 mm.

What are the excavation performance specifications of the Hidromek HMK 140 LC?

The Hidromek HMK 140 LC has a dredging depth of 5.14 meters, a maximum horizontal reach of 8.2 meters, and features a monobloc boom.

What power ratings are available for the Hidromek HMK 140 LC?

There are no power ratings provided for the Hidromek HMK 140 LC in the available data.

What are the specifications of the primary work tool bucket on the Hidromek HMK 140 LC?

The primary work tool bucket of the Hidromek HMK 140 LC has a capacity of 0.6 cubic meters and a width of 0.98 meters.

How much is a Hidromek HMK 140 LC Crawler excavator (2010u20132011) worth?

The residual value of the Hidromek HMK 140 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
