N085UJ Long Hanix excavator specs & Dimensions (2019 - 2026)

Hanix N085UJ Long is a Crawler Excavator manufactured since 2019, with a weight of 8.31 t and a track width of 450 mm. It has a tr…

Hanix N085UJ Long is a Crawler Excavator manufactured since 2019, with a weight of 8.31 t and a track width of 450 mm. It has a transport length of 6.48 m, a transport width of 2.2 m, and a transport height of 2.57 m. The excavator features a tear-out force of 54.8 kN, a dredging depth of 4.5 m, and a maximum horizontal reach of 7.13 m. The bucket width is 0.75 m with a capacity of 0.25 m³. Special equipment includes air conditioning and a blade.

Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long
Crawler Excavators Hanix N085UJ Long

Technical specs - N085UJ Long Hanix

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.31 t
Transport length
6.48 m
Transport width
2.2 m
Transport height
2.57 m
Bucket capacity
0.25 m³
Track width
450 mm
Max. Reach horizontal
7.13 m
Dredging depth
4.5 m
Tear-out force
54.8 kN
Bucket width
0.75 m
Model series
N
Engine manuf.
Kubota
Engine type
V2607
Engine power
43 kW
Displacement
2.615 l
Revolutions at max torque
2200 rpm
Max. torque
219.2 Nm
No. of cylinders
4

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hanix N085UJ Long FAQ

When was the Hanix N085UJ Long manufactured?

The Hanix N085UJ Long was first produced in 2019.

How much does the Hanix N085UJ Long weigh?

The Hanix N085UJ Long weighs 8.31 tons.

What are the transport dimensions of the Hanix N085UJ Long crawler excavator?

The Hanix N085UJ Long crawler excavator has a transport length of 6.48 meters, a transport width of 2.2 meters, and a transport height of 2.57 meters.

What is the track width of the Hanix N085UJ Long's undercarriage?

The Hanix N085UJ Long has a track width of 450 mm.

What is the excavation performance of the Hanix N085UJ Long?

The Hanix N085UJ Long has a dredging depth of 4.5 meters and a maximum horizontal reach of 7.13 meters.

What is the tear-out force of the Hanix N085UJ Long?

The Hanix N085UJ Long has a tear-out force of 54.8 kN.

What are the bucket specifications of the Hanix N085UJ Long crawler excavator?

The Hanix N085UJ Long has a bucket capacity of 0.25 cubic meters and a bucket width of 0.75 meters.

How much is a Hanix N085UJ Long Crawler excavator (2019u20132025) worth?

The residual value of the Hanix N085UJ Long depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hanix N085UJ Long overview

Hydraulics

Wide opening engine canopy allows good access for daily checks and routine servicing tasks.
The N085uj is a robust machine, ideally suited for demanding tasks where reach and digging performance are essential. With the combination of a fuel efficient Kubota engine and a hydraulic variable displacement piston pump, the power of the machine is optimized to maximum productivity. Equipped with steel build-up throughout and a wrap-around counterweight, it fits well into site toughness conditions. In addition, the grab mounted 2-way auxiliary hydraulic control ensures maximum versatility with the ability to use different attachments.

Dimensions and weight

MACHINE SPECIFICATIONSSHORT ARMLONG ARM
Machine Weight - Cabin Rubber Trackskg82908315
Dimensions (Length / Width / Height)mm6480 / 2200 / 2570
Dozer Blade Dimensions (Width / Height)mm2200 / 495
Noise Level (LwA / LpA)dB(A)98 / 78
Ground Pressure - Cabin Rubber TrackskPa / psi37.5 / 5.4437.6 / 5.45
ENGINE
Make / Model / Cylinders / Displacement (cc)Kubota / V2607 / 4 / 2615
Rated PowerkW / ps43 / 58.5 @ 2200 rpm
Maximum TorqueNm219.2
WORKING RANGE
Maximum Digging Depthmm43054505
Maximum Digging Heightmm70407170
Maximum Dumping Heightmm50055140
Maximum Vertical Digging Depthmm36253825
Maximum Digging Radiusmm71107300
Maximum Reach at Groundmm69507135
Minimum Turning Radius Frontmm24402480
Minimum Turning Radius Swingmm19201950
Rear Turning Radiusmm1500
Boom Swing Angle (L / R)degreesL75 / R50
PERFORMANCE
Maximum Digging Power (Bucket / Arm)kN54.8 / 3954.8 / 36.3
Travel Speed (Low / High)km/h2.8 / 4.9
Slew Speedrpm12.7
Gradeabilitydegrees25
HYDRAULIC SYSTEM
Hydraulic Pump TypesPiston x 2
Hydraulic Pump Flowslitres / min79.2 x 2 + 26.6
Auxiliary Hydraulic Flow (PTO)litres / min79.2
Relief PressuresMpa25.5 x 2 + 22.6
FLUID CAPACITIES
Fuel Tanklitres125
Hydraulic Tanklitres61
Engine Oillitres10.2
Cooling Systemlitres12
Travel Motor Reduction Gearboxlitres1.1

Other features

Safety
Lever lock prevents inadvertent hydraulic operation and starting of the engine. Battery isolator switch. Auxiliary flow socket for beacon. ROPS & FOPS cab. Retractable seat belt. Exterior mirrors.
