ES 85 SB Eurocomach excavator specs & Dimensions (2014 - 2021)

Eurocomach ES 85 SB is a Crawler Excavator manufactured from 2014 to 2021, with a weight of 8.3 tons. It features a track width of…

Eurocomach ES 85 SB is a Crawler Excavator manufactured from 2014 to 2021, with a weight of 8.3 tons. It features a track width of 450 mm, a transport length of 5.77 meters, a transport width of 2.32 meters, and a transport height of 2.56 meters. The dredging depth is 3.8 meters. Special equipment includes air conditioning, a blade, cabin adjustment, material handling capabilities, an overload alert, and both hydraulic and mechanical quick hitches.

ES 85 SB

Years of manufacture: 2014—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ES 85 SB Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.3 t

Transport length: 5.77 m

Transport width: 2.32 m

Transport height: 2.56 m

Track width: 450 mm

Boom: MB

Dredging depth: 3.8 m

Model series: MME

Engine manuf.: Yanmar

Engine type: 4TNV98

Engine power: 46.3 kW

Displacement: 3.319 l

Max. torque: 239,1/1650 Nm

Emission level: III

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, max. reach horizontal, tear-out force, bucket width, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: Yes
Cabin adjustment: Yes
Overload alert: Yes
Material Handling Excavator: Yes
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

Eurocomach ES 85 SB FAQ

When was the Eurocomach ES 85 SB manufactured?

The Eurocomach ES 85 SB was manufactured from 2014 to 2021.

How much does the Eurocomach ES 85 SB weigh?

The Eurocomach ES 85 SB weighs 8.3 tons.

What are the transport dimensions of the Eurocomach ES 85 SB?

The Eurocomach ES 85 SB has a transport length of 5.77 meters, a transport width of 2.32 meters, and a transport height of 2.56 meters.

What is the track width of the Eurocomach ES 85 SB's undercarriage?

The Eurocomach ES 85 SB has a track width of 450 mm.

What are the excavation performance specifications of the Eurocomach ES 85 SB?

The Eurocomach ES 85 SB has a dredging depth of 3.8 meters and is equipped with a monobloc boom.

How much is a Eurocomach ES 85 SB Crawler excavator (2014u20132021) worth?

The residual value of the Eurocomach ES 85 SB depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
