100 TR Eurocomach excavator specs & Dimensions (2019 - 2023)

Eurocomach 100 TR is a Crawler Excavator manufactured since 2019, with a weight of 9.9 t and a track width of 450 mm. It has a tra…

Eurocomach 100 TR is a Crawler Excavator manufactured since 2019, with a weight of 9.9 t and a track width of 450 mm. It has a transport length of 7.03 m, a transport width of 2.32 m, and a transport height of 2.56 m. The machine features a tear-out force of 58.5 kN, a dredging depth of 4.57 m, and a maximum horizontal reach of 7.73 m. Special equipment includes air conditioning, a blade, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, and both hydraulic and mechanical quick hitch systems.

Crawler Excavators Eurocomach 100 TR

Technical specs - 100 TR Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.9 t
Transport length
7.03 m
Transport width
2.32 m
Transport height
2.56 m
Track width
450 mm
Boom
VA
Max. Reach horizontal
7.73 m
Dredging depth
4.57 m
Tear-out force
58.5 kN
Model series
MME
Engine manuf.
Yanmar
Engine type
4TNV98CT
Engine power
53.7 kW
Displacement
3.319 l
Revolutions at max torque
2300 rpm
Max. torque
308/1365 Nm
No. of cylinders
4
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Eurocomach 100 TR FAQ

When was the Eurocomach 100 TR manufactured?

The Eurocomach 100 TR was manufactured from 2019 to 2023.

How much does the Eurocomach 100 TR weigh?

The Eurocomach 100 TR weighs 9.9 tons.

What are the transport dimensions of the Eurocomach 100 TR?

The Eurocomach 100 TR has a transport length of 7.03 meters, a transport width of 2.32 meters, and a transport height of 2.56 meters.

What is the track width of the Eurocomach 100 TR's undercarriage?

The Eurocomach 100 TR has a track width of 450 mm.

What are the excavation performance specifications of the Eurocomach 100 TR?

The Eurocomach 100 TR has an adjustable boom, a dredging depth of 4.57 meters, and a maximum horizontal reach of 7.73 meters.

What is the tear-out force of the Eurocomach 100 TR, given that no power rating data is available?

The Eurocomach 100 TR has a tear-out force of 58.5 kN. No power rating data is provided in the source.

How much is a Eurocomach 100 TR Crawler excavator (2019u20132023) worth?

The residual value of the Eurocomach 100 TR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
