Solar 75 V Doosan excavator specs & Dimensions (2009 - 2009)

Doosan Solar 75 V is a crawler excavator with a weight of 8 tons, a track width of 450 mm, a transport length of 6.28 meters, a tr…

Doosan Solar 75 V is a crawler excavator with a weight of 8 tons, a track width of 450 mm, a transport length of 6.28 meters, a transport width of 2.21 meters, and a transport height of 3.21 meters. It has a tear-out force of 36 kN and a bucket width of 0.901 meters. This model, manufactured in 2009, is equipped with a blade.

Crawler Excavators Doosan Solar 75 V

Technical specs - Solar 75 V Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8 t
Transport length
6.28 m
Transport width
2.21 m
Transport height
3.21 m
Bucket capacity
0.28 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
7.02 m
Dredging depth
4.42 m
Tear-out force
36 kN
Bucket width
0.901 m
Model series
Solar
Engine manuf.
Yanmar
Engine type
4TNE98XDB
Engine power
39 kW
Displacement
3.32 l
Revolutions at max torque
1900 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Doosan Solar 75 V FAQ

When was the Doosan Solar 75 V manufactured?

The Doosan Solar 75 V was manufactured in 2009.

How much does the Doosan Solar 75 V weigh?

The Doosan Solar 75 V weighs 8 tons.

What are the transport dimensions of the Doosan Solar 75 V?

The Doosan Solar 75 V has a transport length of 6.28 meters, a transport width of 2.21 meters, and a transport height of 3.21 meters.

What is the track width of the Doosan Solar 75 V's undercarriage?

The Doosan Solar 75 V has a track width of 450 mm.

What are the excavation performance specifications of the Doosan Solar 75 V?

The Doosan Solar 75 V has a dredging depth of 4.42 meters, a maximum horizontal reach of 7.02 meters, and is equipped with a Monobloc boom.

What are the power ratings of the Doosan Solar 75 V?

The available data does not provide power ratings for the Doosan Solar 75 V.

What are the bucket specifications of the Doosan Solar 75 V excavator?

The Doosan Solar 75 V excavator has a bucket capacity of 0.28 cubic meters and a bucket width of 0.901 meters.
