335F L Caterpillar excavator specs & Dimensions (2017 - 2020)

Caterpillar 335F L is a crawler excavator manufactured from 2017 to 2020, with a weight of 35.4 tons, a track width of 600 mm, and a bucket capacity of 1.4 m³.

Crawler Excavators Caterpillar 335F L
Crawler Excavators Caterpillar 335F L
Crawler Excavators Caterpillar 335F L
Crawler Excavators Caterpillar 335F L

Technical specs - 335F L Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35.4 t
Bucket capacity
1.4 m³
Track width
600 mm
Boom
MB
Engine manuf.
Caterpillar
Engine type
C7.1 Acert
Engine power
151 kW
Displacement
7 l
Revolutions at max torque
1800 rpm

More technical details, like: transport length, transport width, transport height, bucket capacity min., bucket capacity max., undercarriage, max. reach horizontal, dredging depth, tear-out force, bucket width, model series, dimension lxwxh...

More technical details, like: transport length, transport width, transport height, bucket capacity min., bucket capacity max., undercarriage, max. reach horizontal, dredging depth, tear-out force, bucket width, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 335F L FAQ

When was the Caterpillar 335F L manufactured?

The Caterpillar 335F L was manufactured from 2017 to 2020.

How much does the Caterpillar 335F L weigh?

The Caterpillar 335F L weighs 35.4 tons.

What is the fuel consumption range of the Caterpillar 335F L crawler excavator?

The Caterpillar 335F L crawler excavator has a fuel consumption range of 14 to 20 liters per hour.

What is the track width of the Caterpillar 335F L's undercarriage?

The Caterpillar 335F L has a track width of 600 mm.

What type of boom does the Caterpillar 335F L have?

The Caterpillar 335F L has a Monobloc boom.

What is the bucket capacity of the Caterpillar 335F L crawler excavator?

The bucket capacity of the Caterpillar 335F L crawler excavator is 1.4 cubic meters.

How much is a Caterpillar 335F L Crawler excavator (2017u20132020) worth?

The residual value of the Caterpillar 335F L depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
