320D3 Caterpillar excavator specs & Dimensions (2019 - 2026)

Caterpillar 320D3 is a Crawler Excavator manufactured since 2019. It has a weight of 20.8 tons and a track width of 600 mm. The tr…

Caterpillar 320D3 is a Crawler Excavator manufactured since 2019. It has a weight of 20.8 tons and a track width of 600 mm. The transport dimensions are 9.46 meters in length, 2.8 meters in width, and 3.05 meters in height. The machine features a tear-out force of 140 kN, a dredging depth of 6.3 meters, and a maximum horizontal reach of 9.47 meters. The bucket capacity is 1 cubic meter, and it includes air conditioning as special equipment.

Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3
Crawler Excavators Caterpillar 320D3

Technical specs - 320D3 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.8 t
Transport length
9.46 m
Transport width
2.8 m
Transport height
3.05 m
Bucket capacity
1 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.47 m
Dredging depth
6.3 m
Tear-out force
140 kN
Engine manuf.
Caterpillar
Engine type
ALUW06DTI
Engine power
85 kW
Displacement
5.76 l
Cylinder bore x stroke
104x113 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 320D3 FAQ

When was the Caterpillar 320D3 manufactured?

The Caterpillar 320D3 was first produced in 2019.

How much does the Caterpillar 320D3 weigh?

The Caterpillar 320D3 weighs 20.8 tons.

What are the transport dimensions of the Caterpillar 320D3?

The Caterpillar 320D3 has a transport length of 9.46 meters, a transport width of 2.8 meters, and a transport height of 3.05 meters.

What is the track width of the Caterpillar 320D3's undercarriage?

The Caterpillar 320D3 has a track width of 600 mm.

What are the excavation performance specifications of the Caterpillar 320D3?

The Caterpillar 320D3 has a dredging depth of 6.3 meters, a maximum horizontal reach of 9.47 meters, and features a Monobloc boom.

What is the tear-out force of the Caterpillar 320D3?

The Caterpillar 320D3 has a tear-out force of 140 kN.

What is the bucket capacity of the Caterpillar 320D3 excavator?

The bucket capacity of the Caterpillar 320D3 is 1 cubic meter.

How much is a Caterpillar 320D3 Crawler excavator (2019u20132025) worth?

The residual value of the Caterpillar 320D3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
