320B Caterpillar excavator specs & Dimensions (1992 - 2007)

Caterpillar 320B is a crawler excavator manufactured from 1992 to 2007. It has a weight of 20.62 tons, a track width of 600 mm, a …

Caterpillar 320B is a crawler excavator manufactured from 1992 to 2007. It has a weight of 20.62 tons, a track width of 600 mm, a transport length of 9.42 meters, a transport width of 2.98 meters, and a transport height of 3.43 meters. The dredging depth is 6.86 meters, and the maximum horizontal reach is 10.69 meters.

Crawler Excavators Caterpillar 320B

Technical specs - 320B Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.62 t
Transport length
9.42 m
Transport width
2.98 m
Transport height
3.43 m
Track width
600 mm
Max. Reach horizontal
10.69 m
Dredging depth
6.86 m
Engine manuf.
Caterpillar
Engine type
3066T
Engine power
100 kW
Displacement
6.37 l

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 320B FAQ

When was the Caterpillar 320B manufactured?

The Caterpillar 320B was manufactured from 1992 to 2007.

How much does the Caterpillar 320B weigh?

The Caterpillar 320B weighs 20.62 tons.

What are the transport dimensions of the Caterpillar 320B crawler excavator?

The Caterpillar 320B has a transport length of 9.42 meters, a transport width of 2.98 meters, and a transport height of 3.43 meters.

What is the track width of the Caterpillar 320B's undercarriage?

The Caterpillar 320B has a track width of 600 mm on its undercarriage.

What are the excavation performance specifications of the Caterpillar 320B?

The Caterpillar 320B has a dredging depth of 6.86 meters and a maximum horizontal reach of 10.69 meters.

How much is a Caterpillar 320B Crawler excavator (1992u20132007) worth?

The residual value of the Caterpillar 320B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
