313F L GC Caterpillar excavator specs & Dimensions (2015 - 2021)

Caterpillar 313F L GC is a crawler excavator manufactured from 2015 to 2021. It has a weight of 13.2 tons and a track width of 500…

Caterpillar 313F L GC is a crawler excavator manufactured from 2015 to 2021. It has a weight of 13.2 tons and a track width of 500 mm. The transport dimensions are 7.68 meters in length, 2.49 meters in width, and 2.83 meters in height. The machine features a tear-out force of 85 kN, a dredging depth of 5.54 meters, and a maximum horizontal reach of 8.17 meters. The bucket width is 0.9 meters with a capacity of 0.53 cubic meters. Special equipment includes air conditioning and a blade.

Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC
Crawler Excavators Caterpillar 313F L GC

Technical specs - 313F L GC Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.2 t
Transport length
7.68 m
Transport width
2.49 m
Transport height
2.83 m
Bucket capacity
0.53 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.17 m
Dredging depth
5.54 m
Tear-out force
85 kN
Bucket width
0.9 m
Engine manuf.
Caterpillar
Engine type
C3.4B
Engine power
55 kW
Displacement
3.4 l
Cylinder bore x stroke
99x110 mm
Emission level
Stage IIIB

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 313F L GC FAQ

When was the Caterpillar 313F L GC manufactured?

The Caterpillar 313F L GC was manufactured from 2015 to 2021.

How much does the Caterpillar 313F L GC weigh?

The Caterpillar 313F L GC weighs 13.2 tons.

What are the transport dimensions of the Caterpillar 313F L GC crawler excavator?

The Caterpillar 313F L GC has a transport length of 7.68 meters, a transport width of 2.49 meters, and a transport height of 2.83 meters.

What is the fuel consumption range of the Caterpillar 313F L GC?

The Caterpillar 313F L GC has a fuel consumption range of 6 to 10 liters per hour.

What is the track width of the Caterpillar 313F L GC's undercarriage?

The Caterpillar 313F L GC has a track width of 500 mm.

What are the excavation performance specifications of the Caterpillar 313F L GC?

The Caterpillar 313F L GC has a dredging depth of 5.54 meters, a maximum horizontal reach of 8.17 meters, and is equipped with a monobloc boom.

What are the power ratings of the Caterpillar 313F L GC?

Power rating data for the Caterpillar 313F L GC is not available in the provided information.

What are the bucket specifications of the Caterpillar 313F L GC excavator?

The Caterpillar 313F L GC excavator has a bucket capacity of 0.53 cubic meters and a bucket width of 0.9 meters.

How much is a Caterpillar 313F L GC Crawler excavator (2015u20132021) worth?

The residual value of the Caterpillar 313F L GC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
