313F L   Caterpillar excavator specs & Dimensions (2017 - 2020)

Caterpillar 313F L is a Crawler Excavator manufactured from 2017 to 2020, with a weight of 13.5 tons. It features a track width of…

Caterpillar 313F L is a Crawler Excavator manufactured from 2017 to 2020, with a weight of 13.5 tons. It features a track width of 500 mm, a transport length of 7.69 meters, a transport width of 2.49 meters, and a transport height of 2.82 meters. The machine has a tear-out force of 85 kN, a dredging depth of 5.14 meters, and a maximum horizontal reach of 7.79 meters. The bucket width is 0.9 meters, and the bucket capacity is 0.53 cubic meters.

Crawler Excavators Caterpillar 313F L
Crawler Excavators Caterpillar 313F L
Crawler Excavators Caterpillar 313F L
Crawler Excavators Caterpillar 313F L

Technical specs - 313F L   Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.5 t
Transport length
7.69 m
Transport width
2.49 m
Transport height
2.82 m
Bucket capacity
0.53 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
7.79 m
Dredging depth
5.14 m
Tear-out force
85 kN
Bucket width
0.9 m
Engine manuf.
Caterpillar
Engine type
C4.4 Acert
Engine power
74 kW
Displacement
4.4 l
Cylinder bore x stroke
105x127 mm
Emission level
Stage IV/Tier 4 Final

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 313F L   FAQ

When was the Caterpillar 313F L manufactured?

The Caterpillar 313F L was manufactured from 2017 to 2020.

How much does the Caterpillar 313F L weigh?

The Caterpillar 313F L weighs 13.5 tons.

What are the transport dimensions of the Caterpillar 313F L crawler excavator?

The Caterpillar 313F L crawler excavator has a transport length of 7.69 meters, a transport width of 2.49 meters, and a transport height of 2.82 meters.

What is the fuel consumption range of the Caterpillar 313F L crawler excavator?

The Caterpillar 313F L crawler excavator has a fuel consumption range of 6 to 9 liters per hour.

What is the track width of the Caterpillar 313F L's undercarriage?

The Caterpillar 313F L has a track width of 500 mm.

What are the excavation performance specifications of the Caterpillar 313F L?

The Caterpillar 313F L has a dredging depth of 5.14 meters, a maximum horizontal reach of 7.79 meters, and features a monobloc boom.

What is the power rating of the Caterpillar 313F L?

The available data does not provide a power rating for the Caterpillar 313F L.

What are the specifications of the primary work tool bucket on the Caterpillar 313F L?

The primary work tool bucket of the Caterpillar 313F L has a capacity of 0.53 cubic meters and a width of 0.9 meters.

How much is a Caterpillar 313F L u00a0 Crawler excavator (2017u20132020) worth?

The residual value of the Caterpillar 313F L u00a0 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
