313D2 L Caterpillar excavator specs & Dimensions (2017 - 2026)

Caterpillar 313D2 L is a crawler excavator manufactured since 2017. It has a weight of 13.7 tons and a track width of 600 mm. The …

Caterpillar 313D2 L is a crawler excavator manufactured since 2017. It has a weight of 13.7 tons and a track width of 600 mm. The transport dimensions are 7.62 meters in length, 2.59 meters in width, and 2.83 meters in height. The dredging depth is 6.04 meters, with a maximum horizontal reach of 8.63 meters. The bucket width is 0.9 meters, and the bucket capacity is 0.53 cubic meters.

Crawler Excavators Caterpillar 313D2 L
Crawler Excavators Caterpillar 313D2 L
Crawler Excavators Caterpillar 313D2 L
Crawler Excavators Caterpillar 313D2 L

Technical specs - 313D2 L Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.7 t
Transport length
7.62 m
Transport width
2.59 m
Transport height
2.83 m
Bucket capacity
0.53 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.63 m
Dredging depth
6.04 m
Bucket width
0.9 m
Engine manuf.
Caterpillar
Engine type
C4.4 Acert
Engine power
68 kW
Displacement
4.4 l
Cylinder bore x stroke
105x127 mm
Emission level
U.S. EPA Tier 3 / EU IIIA

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 313D2 L FAQ

When was the Caterpillar 313D2 L manufactured?

The Caterpillar 313D2 L was first produced in 2017.

How much does the Caterpillar 313D2 L weigh?

The Caterpillar 313D2 L weighs 13.7 tons.

What are the transport dimensions of the Caterpillar 313D2 L crawler excavator?

The Caterpillar 313D2 L has a transport length of 7.62 meters, a transport width of 2.59 meters, and a transport height of 2.83 meters.

What is the fuel consumption of the Caterpillar 313D2 L crawler excavator?

The Caterpillar 313D2 L has a fuel consumption range of 6 to 11 liters per hour, with an average consumption of 8.4 liters per hour.

What are the undercarriage specifications of the Caterpillar 313D2 L?

The Caterpillar 313D2 L has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Caterpillar 313D2 L?

The Caterpillar 313D2 L has a dredging depth of 6.04 meters, a maximum horizontal reach of 8.63 meters, and features a monobloc boom.

What are the specifications of the primary work tool on the Caterpillar 313D2 L?

The primary work tool of the Caterpillar 313D2 L has a bucket capacity of 0.53 cubic meters and a bucket width of 0.9 meters.

How much is a Caterpillar 313D2 L Crawler excavator (2017u20132025) worth?

The residual value of the Caterpillar 313D2 L depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
