CX75C SR Case excavator specs & Dimensions (2013 - 2018)

Model rating
8,00 / 10

Case CX75C SR is a Crawler Excavator manufactured from 2013 to 2018. It has a weight of 8 tons and a track width of 450 mm. The tr…

Case CX75C SR is a Crawler Excavator manufactured from 2013 to 2018. It has a weight of 8 tons and a track width of 450 mm. The transport dimensions are 5.755 meters in length, 2.32 meters in width, and 2.76 meters in height. The excavator features a tear-out force of 56.9 kN, a dredging depth of 4.13 meters, and a maximum horizontal reach of 6.41 meters. The bucket width is 0.8 meters with a capacity of 0.28 cubic meters. Special equipment includes air conditioning, a blade, an overload alert, and a hydraulic quick hitch.

Crawler Excavators Case CX75C SR

Technical specs - CX75C SR Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8 t
Transport length
5.755 m
Transport width
2.32 m
Transport height
2.76 m
Bucket capacity
0.28 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
6.41 m
Dredging depth
4.13 m
Tear-out force
56.9 kN
Bucket width
0.8 m
Model series
C
Engine manuf.
Isuzu
Engine type
AP-4LE2X
Engine power
41.2 kW
Displacement
2.179 l
Revolutions at max torque
1800 rpm
Max. torque
193 Nm
Emission level
Tier 4 Final / Stage IIIB

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Case CX75C SR FAQ

When was the Case CX75C SR manufactured?

The Case CX75C SR was manufactured from 2013 to 2018.

How much does the Case CX75C SR weigh?

The Case CX75C SR weighs 8 tons.

What are the transport dimensions of the Case CX75C SR crawler excavator?

The Case CX75C SR has a transport length of 5.76 meters, a transport width of 2.32 meters, and a transport height of 2.76 meters.

What is the track width of the Case CX75C SR crawler excavator?

The Case CX75C SR crawler excavator has a track width of 450 mm.

What are the excavation performance specifications of the Case CX75C SR?

The Case CX75C SR has a dredging depth of 4.13 meters, a maximum horizontal reach of 6.41 meters, and is equipped with a monobloc boom.

What are the power ratings of the Case CX75C SR?

The source data does not provide power ratings for the Case CX75C SR. It only specifies a tear-out force of 56.9 kN, which is a force measurement, not a power rating.

What are the specifications of the primary work tool bucket on the Case CX75C SR?

The primary work tool bucket of the Case CX75C SR has a capacity of 0.28 cubic meters and a width of 0.8 meters.

How much is a Case CX75C SR Crawler excavator (2013u20132018) worth?

The residual value of the Case CX75C SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
