CX180E Case excavator specs & Dimensions (2022 - 2026)

Case CX180E is a Crawler Excavator manufactured since 2022. It has a weight of 18.4 tons and a track width of 600 mm. The transpor…

Case CX180E is a Crawler Excavator manufactured since 2022. It has a weight of 18.4 tons and a track width of 600 mm. The transport dimensions are 8.51 meters in length, 2.8 meters in width, and 3.07 meters in height. The excavator features a tear-out force of 112 kN, a dredging depth of 6.04 meters, and a maximum horizontal reach of 8.87 meters. The bucket width is 0.9 meters with a capacity of 0.62 cubic meters. Special equipment includes air conditioning, a diesel particulate filter, an overload alert, and a hydraulic quick hitch.

Crawler Excavators Case CX180E

Technical specs - CX180E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.4 t
Transport length
8.51 m
Transport width
2.8 m
Transport height
3.07 m
Bucket capacity
0.62 m³
Undercarriage
SL
Track width
600 mm
Boom
MB
Max. Reach horizontal
8.87 m
Dredging depth
6.04 m
Tear-out force
112 kN
Bucket width
0.9 m
Model series
E
Engine manuf.
FPT
Engine type
NEF4
Engine power
90.4 kW
Displacement
4.5 l
Revolutions at max torque
1600 rpm
Max. torque
456 Nm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
EU V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Case CX180E FAQ

When was the Case CX180E manufactured?

The Case CX180E was first produced in 2022.

How much does the Case CX180E crawler excavator weigh?

The Case CX180E crawler excavator weighs 18.4 tons.

What are the transport dimensions of the Case CX180E crawler excavator?

The Case CX180E has a transport length of 8.51 meters, a transport width of 2.8 meters, and a transport height of 3.07 meters.

What are the undercarriage specifications of the Case CX180E?

The Case CX180E has a standard undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Case CX180E?

The Case CX180E has a dredging depth of 6.04 meters, a maximum horizontal reach of 8.87 meters, and features a Monobloc boom.

What is the tear-out force of the Case CX180E?

The Case CX180E has a tear-out force of 112 kN.

What are the bucket specifications of the Case CX180E crawler excavator?

The Case CX180E has a bucket capacity of 0.62 cubic meters and a bucket width of 0.9 meters.

How much is a Case CX180E Crawler excavator (2022u20132025) worth?

The residual value of the Case CX180E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
