CX130E Case excavator specs & Dimensions (2023 - 2026)

Weight: 15.1t – Transport length: 10.43m – Transport width: 2.69m – Transport height: 2.92m – Bucket capacity: 0.28m³ – Undercarri…

Weight: 15.1t – Transport length: 10.43m – Transport width: 2.69m – Transport height: 2.92m – Bucket capacity: 0.28m³ – Undercarriage: SL

Check out detailed specifications, information and technical data for Case CX130E excavator manufactured between 2023 - 2026. Get more in-depth insight with Case CX130E digger specifications. See information, like: Weight: 15.1t – Transport length: 10.43m – Transport width: 2.69m – Transport height: 2.92m – Bucket capacity: 0.28m³ – Undercarriage: SL and more.

Crawler Excavators Case CX130E

Technical specs - CX130E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.1 t
Transport length
10.43 m
Transport width
2.69 m
Transport height
2.92 m
Bucket capacity
0.28 m³
Undercarriage
SL
Track width
700 mm
Boom
MB
Max. Reach horizontal
13.1 m
Dredging depth
10.13 m
Tear-out force
35 kN
Bucket width
0.7 m
Model series
E
Engine manuf.
FPT
Engine type
NEF4
Engine power
76.4 kW
Displacement
4.5 l
Revolutions at max torque
1800 rpm
Max. torque
370 Nm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
EU V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Case CX130E FAQ

When was the Case CX130E manufactured?

The Case CX130E was first produced in 2023.

How much does the Case CX130E crawler excavator weigh?

The Case CX130E crawler excavator weighs 15.1 tons.

What are the transport dimensions of the Case CX130E crawler excavator?

The transport dimensions of the Case CX130E are 10.43 meters in length, 2.69 meters in width, and 2.92 meters in height.

What are the undercarriage specifications of the Case CX130E?

The Case CX130E has a standard undercarriage with a track width of 700 mm.

What are the excavation performance specifications of the Case CX130E?

The Case CX130E has a dredging depth of 10.13 meters, a maximum horizontal reach of 13.1 meters, and is equipped with a monobloc boom.

What is the power rating of the Case CX130E?

The power rating of the Case CX130E is not provided in the available data.

What are the specifications of the primary work tool bucket on the Case CX130E?

The primary work tool bucket of the Case CX130E has a capacity of 0.28 cubic meters and a width of 0.7 meters.

How much is a Case CX130E Crawler excavator (2023u20132025) worth?

The residual value of the Case CX130E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
