CX 75 SR Case excavator specs & Dimensions (2008 - 2012)

Case CX 75 SR is a crawler excavator manufactured from 2008 to 2012, with a weight of 8.15 tons. It features a track width of 600 …

Case CX 75 SR is a crawler excavator manufactured from 2008 to 2012, with a weight of 8.15 tons. It features a track width of 600 mm, a transport length of 5.91 meters, a transport width of 2.7 meters, and a transport height of 2.32 meters. The excavator is equipped with air conditioning and a blade.

CX 75 SR

Years of manufacture: 2008—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CX 75 SR Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.15 t

Transport length: 5.91 m

Transport width: 2.7 m

Transport height: 2.32 m

Bucket capacity: 0.36 m³

Track width: 600 mm

Boom: MB

Max. Reach horizontal: 6.9 m

Dredging depth: 4.54 m

Tear-out force: 56.9 kN

Bucket width: 0.85 m

Model series: SR

Engine manuf.: Isuzu

Engine type: AU-4LE2X

Engine power: 40 kW

Revolutions at max torque: 1500 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: Yes
Cabin adjustment: No
Overload alert: No
Material Handling Excavator: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Case CX 75 SR FAQ

When was the Case CX 75 SR manufactured?

The Case CX 75 SR was manufactured from 2008 to 2012.

How much does the Case CX 75 SR weigh?

The Case CX 75 SR weighs 8.15 tons.

What are the transport dimensions of the Case CX 75 SR crawler excavator?

The Case CX 75 SR crawler excavator has a transport length of 5.91 meters, a transport width of 2.7 meters, and a transport height of 2.32 meters.

What is the track width of the Case CX 75 SR crawler excavator?

The Case CX 75 SR crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the Case CX 75 SR?

The Case CX 75 SR has a dredging depth of 4.54 meters, a maximum horizontal reach of 6.9 meters, and is equipped with a monobloc boom.

Are there any power ratings available for the Case CX 75 SR?

The source data does not provide any power ratings for the Case CX 75 SR.

What are the specifications of the primary work tool bucket on the Case CX 75 SR?

The primary work tool bucket of the Case CX 75 SR has a capacity of 0.36 cubic meters and a width of 0.85 meters.

How much is a Case CX 75 SR Crawler excavator (2008u20132012) worth?

The residual value of the Case CX 75 SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
