CX 210 LC Case excavator specs & Dimensions (2003 - 2015)

Case CX 210 LC is a Crawler Excavator manufactured from 2003 to 2015, with a weight of 20.4 tons. It features a track width of 800…

Case CX 210 LC is a Crawler Excavator manufactured from 2003 to 2015, with a weight of 20.4 tons. It features a track width of 800 mm, a transport length of 9.49 meters, a transport width of 3.19 meters, and a transport height of 3.07 meters. The excavator has a tear-out force of 126 kN, a dredging depth of 6.7 meters, and a maximum horizontal reach of 9.8 meters. The bucket width is 1.45 meters, with a bucket capacity ranging from 0.41 m³ to 1.25 m³.

Crawler Excavators Case CX 210 LC

Technical specs - CX 210 LC Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.4 t
Transport length
9.49 m
Transport width
3.19 m
Transport height
3.07 m
Bucket capacity
1.25 m³
Bucket capacity min.
0.41 m³
Bucket capacity max.
1.25 m³
Undercarriage
LC
Track width
800 mm
Boom
MB
Max. Reach horizontal
9.8 m
Dredging depth
6.7 m
Tear-out force
126 kN
Bucket width
1.45 m
Engine manuf.
Isuzu
Engine type
BB-6BG1T
Engine power
105 kW
Displacement
6.494 l
Revolutions at max torque
1950 rpm

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX 210 LC FAQ

When was the Case CX 210 LC manufactured?

The Case CX 210 LC was manufactured from 2003 to 2015.

How much does the Case CX 210 LC weigh?

The Case CX 210 LC weighs 20.4 tons.

What are the transport dimensions of the Case CX 210 LC crawler excavator?

The Case CX 210 LC has a transport length of 9.49 meters, a transport width of 3.19 meters, and a transport height of 3.07 meters.

What are the undercarriage specifications of the Case CX 210 LC?

The Case CX 210 LC has a long undercarriage and a track width of 800 mm.

What are the excavation performance specifications of the Case CX 210 LC?

The Case CX 210 LC has a dredging depth of 6.7 meters, a maximum horizontal reach of 9.8 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Case CX 210 LC?

The Case CX 210 LC has a tear-out force of 126 kN. Note that the source data does not provide power ratings for this machine.

What are the specifications of the primary work tool bucket on the Case CX 210 LC?

The Case CX 210 LC has a bucket with a capacity ranging from 0.41 to 1.25 cubic meters and a bucket width of 1.45 meters.
