CX 210 Case excavator specs & Dimensions (2005 - 2015)

Case CX 210 is a Crawler Excavator manufactured from 2005 to 2015. It has a weight of 19.96 tons and a track width of 800 mm. The …

Case CX 210 is a Crawler Excavator manufactured from 2005 to 2015. It has a weight of 19.96 tons and a track width of 800 mm. The transport dimensions are 9.55 meters in length, 3.2 meters in width, and 3.07 meters in height. The excavator features a tear-out force of 127 kN, a dredging depth of 6.71 meters, and a maximum horizontal reach of 9.78 meters. The bucket width is 1.68 meters, with a capacity ranging from 0.38 m³ to 1.15 m³.

Crawler Excavators Case CX 210

Technical specs - CX 210 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.96 t
Transport length
9.55 m
Transport width
3.2 m
Transport height
3.07 m
Bucket capacity
1.15 m³
Bucket capacity min.
0.38 m³
Bucket capacity max.
1.15 m³
Track width
800 mm
Max. Reach horizontal
9.78 m
Dredging depth
6.71 m
Tear-out force
127 kN
Bucket width
1.68 m
Engine manuf.
Case
Engine type
6TAA-5904
Engine power
114 kW
Displacement
5.9 l
Revolutions at max torque
1400 rpm
Max. torque
610 Nm
No. of cylinders
6
Cylinder bore x stroke
102x120 mm
Emission level
Tier II

More technical details, like: undercarriage, boom, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX 210 FAQ

When was the Case CX 210 manufactured?

The Case CX 210 was manufactured from 2005 to 2015.

How much does the Case CX 210 weigh?

The Case CX 210 weighs 19.96 tons.

What are the transport dimensions of the Case CX 210 crawler excavator?

The Case CX 210 has a transport length of 9.55 meters, a transport width of 3.2 meters, and a transport height of 3.07 meters.

What is the track width of the Case CX 210's undercarriage?

The Case CX 210 has a track width of 800 mm.

What are the excavation performance specifications of the Case CX 210?

The Case CX 210 has a dredging depth of 6.71 meters and a maximum horizontal reach of 9.78 meters.

What are the power ratings of the Case CX 210?

The source data does not provide power rating information for the Case CX 210.

What are the specifications of the bucket on the Case CX 210 crawler excavator?

The Case CX 210 has a bucket with a capacity ranging from 0.38 to 1.15 cubic meters and a bucket width of 1.68 meters.

How much is a Case CX 210 Crawler excavator (2005u20132015) worth?

The residual value of the Case CX 210 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
