9030B Case excavator specs & Dimensions (1995 - 2015)

Case 9030B is a Crawler Excavator manufactured from 1995 to 2015. It has a weight of 20.2 tons and a track width of 813 mm. The tr…

Case 9030B is a Crawler Excavator manufactured from 1995 to 2015. It has a weight of 20.2 tons and a track width of 813 mm. The transport dimensions are 9.55 meters in length, 3.2 meters in width, and 3.06 meters in height. The machine features a tear-out force of 114 kN, a dredging depth of 6.68 meters, and a maximum horizontal reach of 9.75 meters. The bucket width is 1.83 meters, with a capacity ranging from 0.45 m³ to 1.06 m³.

Crawler Excavators Case 9030B

Technical specs - 9030B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.2 t
Transport length
9.55 m
Transport width
3.2 m
Transport height
3.06 m
Bucket capacity
1.06 m³
Bucket capacity min.
0.45 m³
Bucket capacity max.
1.06 m³
Undercarriage
HD
Track width
813 mm
Max. Reach horizontal
9.75 m
Dredging depth
6.68 m
Tear-out force
114 kN
Bucket width
1.83 m
Model series
B
Engine manuf.
Case
Engine type
6T 590
Engine power
95 kW
Displacement
5.9 l
Revolutions at max torque
1500 rpm
Max. torque
500 Nm
No. of cylinders
6
Cylinder bore x stroke
102x120 mm

More technical details, like: boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 9030B FAQ

When was the Case 9030B manufactured?

The Case 9030B was manufactured from 1995 to 2015.

How much does the Case 9030B weigh?

The Case 9030B weighs 20.2 tons.

What are the transport dimensions of the Case 9030B crawler excavator?

The Case 9030B has a transport length of 9.55 meters, a width of 3.2 meters, and a height of 3.06 meters.

What are the undercarriage specifications of the Case 9030B crawler excavator?

The Case 9030B crawler excavator has a heavy duty undercarriage with a track width of 813 mm.

What is the excavation performance of the Case 9030B?

The Case 9030B has a dredging depth of 6.68 meters and a maximum horizontal reach of 9.75 meters.

What is the tear-out force of the Case 9030B?

The Case 9030B has a tear-out force of 114 kN. No power rating data is provided in the source.

What are the specifications of the bucket on the Case 9030B crawler excavator?

The Case 9030B crawler excavator has a bucket with a capacity ranging from 0.45 to 1.06 cubic meters and a width of 1.83 meters.

How much is a Case 9030B Crawler excavator (1995u20132015) worth?

The residual value of the Case 9030B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
