9010B Case excavator specs & Dimensions (1996 - 2015)

Case 9010B is a Crawler Excavator manufactured from 1996 to 2015. It has a weight of 12.77 tons and a track width of 600 mm. The t…

Case 9010B is a Crawler Excavator manufactured from 1996 to 2015. It has a weight of 12.77 tons and a track width of 600 mm. The transport dimensions are 7.63 meters in length, 2.59 meters in width, and 2.77 meters in height. The excavator features a tear-out force of 78 kN, a dredging depth of 6.05 meters, and a maximum horizontal reach of 8.66 meters. The bucket width is 1.52 meters, with a capacity ranging from 0.38 to 0.7 cubic meters. It is equipped with a blade as special equipment.

Crawler Excavators Case 9010B

Technical specs - 9010B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12.77 t
Transport length
7.63 m
Transport width
2.59 m
Transport height
2.77 m
Bucket capacity
0.7 m³
Bucket capacity min.
0.38 m³
Bucket capacity max.
0.7 m³
Undercarriage
HD
Track width
600 mm
Max. Reach horizontal
8.66 m
Dredging depth
6.05 m
Tear-out force
78 kN
Bucket width
1.52 m
Model series
B
Engine manuf.
Case
Engine type
4TA 390
Engine power
75 kW
Displacement
3.9 l
Revolutions at max torque
1600 rpm
Max. torque
393 Nm
No. of cylinders
4
Cylinder bore x stroke
102x120 mm

More technical details, like: boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 9010B FAQ

When was the Case 9010B manufactured?

The Case 9010B was manufactured from 1996 to 2015.

How much does the Case 9010B weigh?

The Case 9010B weighs 12.77 tons.

What are the transport dimensions of the Case 9010B crawler excavator?

The Case 9010B crawler excavator has a transport length of 7.63 meters, a transport width of 2.59 meters, and a transport height of 2.77 meters.

What are the undercarriage specifications of the Case 9010B crawler excavator?

The Case 9010B crawler excavator has a heavy duty undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Case 9010B?

The Case 9010B has a dredging depth of 6.05 meters and a maximum horizontal reach of 8.66 meters.

What are the power ratings of the Case 9010B crawler excavator?

The source data does not provide power rating information for the Case 9010B crawler excavator.

What are the bucket specifications of the Case 9010B crawler excavator?

The Case 9010B crawler excavator has a bucket capacity of 0.7 cubic meters, with a maximum capacity of 0.7 cubic meters, a minimum capacity of 0.38 cubic meters, and a bucket width of 1.52 meters.

How much is a Case 9010B Crawler excavator (1996u20132015) worth?

The residual value of the Case 9010B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
