1080B Case excavator specs & Dimensions (1986 - 2015)

Case 1080B is a Crawler Excavator manufactured from 1986 to 2015. It has a weight of 20.03 tons and a track width of 610 mm. The t…

Case 1080B is a Crawler Excavator manufactured from 1986 to 2015. It has a weight of 20.03 tons and a track width of 610 mm. The transport dimensions are 9.25 meters in length, 2.87 meters in width, and 3.33 meters in height. The excavator features a tear-out force of 120 kN, a dredging depth of 6.84 meters, and a maximum horizontal reach of 9.67 meters. The bucket width is 1.8 meters, with a capacity ranging from 0.37 m³ to 0.76 m³.

Crawler Excavators Case 1080B

Visit Case live at

Technical specs - 1080B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.03 t
Transport length
9.25 m
Transport width
2.87 m
Transport height
3.33 m
Bucket capacity
0.76 m³
Bucket capacity min.
0.37 m³
Bucket capacity max.
0.76 m³
Track width
610 mm
Max. Reach horizontal
9.67 m
Dredging depth
6.84 m
Tear-out force
120 kN
Bucket width
1.8 m
Model series
B
Engine manuf.
Case
Engine type
504 BDT
Engine power
127 kW
Displacement
8.26 l
Revolutions at max torque
1500 rpm
Max. torque
658 Nm
No. of cylinders
6
Cylinder bore x stroke
117.4x127 mm

More technical details, like: undercarriage, boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 1080B FAQ

When was the Case 1080B manufactured?

The Case 1080B was manufactured from 1986 to 2015.

How much does the Case 1080B weigh?

The Case 1080B weighs 20.03 tons.

What are the transport dimensions of the Case 1080B crawler excavator?

The Case 1080B crawler excavator has a transport length of 9.25 meters, a transport width of 2.87 meters, and a transport height of 3.33 meters.

What is the track width of the Case 1080B crawler excavator?

The Case 1080B crawler excavator has a track width of 610 mm.

What is the excavation performance of the Case 1080B crawler excavator?

The Case 1080B crawler excavator has a dredging depth of 6.84 meters and a maximum horizontal reach of 9.67 meters.

What are the power ratings of the Case 1080B?

The available data does not include power ratings for the Case 1080B.

What are the bucket specifications of the Case 1080B crawler excavator?

The Case 1080B crawler excavator has a bucket capacity of 0.76 cubic meters, with a minimum capacity of 0.37 cubic meters and a maximum capacity of 0.76 cubic meters, and a bucket width of 1.8 meters.
