H25C Akerman-Volvo excavator specs & Dimensions (1980 - 1991)

Akerman-Volvo H25C is a crawler excavator manufactured from 1980 to 1991. It has a weight of 54 tons, a track width of 800 mm, a t…

Akerman-Volvo H25C is a crawler excavator manufactured from 1980 to 1991. It has a weight of 54 tons, a track width of 800 mm, a transport width of 4 meters, and a transport height of 4 meters. The dredging depth is 9 meters, and the maximum horizontal reach is 11 meters.

Crawler Excavators Akerman-Volvo H25C

Technical specs - H25C Akerman-Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
54 t
Transport width
4.15 m
Transport height
4.4 m
Track width
800 mm
Max. Reach horizontal
11.7 m
Dredging depth
9 m
Engine manuf.
Volvo Penta
Engine type
TD120C
Engine power
271 kW
Displacement
11.98 l
Revolutions at max torque
1800 rpm

More technical details, like: transport length, bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, model series, dimension lxwxh, max. torque, no. of cylinders...

More technical details, like: transport length, bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Akerman-Volvo H25C FAQ

When was the Akerman-Volvo H25C manufactured?

The Akerman-Volvo H25C was manufactured from 1980 to 1991.

How much does the Akerman-Volvo H25C weigh?

The Akerman-Volvo H25C weighs 54 tons.

What are the transport dimensions of the Akerman-Volvo H25C?

The Akerman-Volvo H25C has a transport width of 4.15 meters and a transport height of 4.4 meters.

What is the track width of the Akerman-Volvo H25C's undercarriage?

The Akerman-Volvo H25C has a track width of 800 mm.

What are the excavation performance specifications of the Akerman-Volvo H25C?

The Akerman-Volvo H25C has a dredging depth of 9 meters and a maximum horizontal reach of 11.7 meters.
