TL 441-13 Liebherr Telehandler Specs & Dimensions (2012 - 2014)

The Liebherr TL 441-13 is a telehandler manufactured by Liebherr from 2012 to 2014. It has a weight of 9.754 tons and a transport …

The Liebherr TL 441-13 is a telehandler manufactured by Liebherr from 2012 to 2014. It has a weight of 9.754 tons and a transport length of 5.884 meters. The maximum horizontal reach is 8.944 meters, and it can lift a nominal load of 4.1 tons at the center of gravity. The lifting height is 12.969 meters, and it has a capacity of 0.25 tons at full forward reach. The travel speed is 25 km/h. At full lift height, it can carry a capacity of 2.2 tons. The transport width is 2.4 meters, and the transport height is 2.395 meters.

Telehandlers Liebherr TL 441-13

Visit Liebherr live at

Technical specs - TL 441-13 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
4.1 t
Model series
TL
Standard tyres
405/70-24
Transmission type
HY
Max. Reach horizontal
8.944 m
Capacity at full forward reach
0.25 t
Lifting height
12.969 m
Capacity at full lift height
2.2 t
Weight
9.754 t
Transport length
5.884 m
Transport width
2.4 m
Transport height
2.395 m
Travel speed
25 km/h
Engine manuf.
John Deere
Engine type
4045HF287
Engine power
74 kW

More technical details, like: centre of gravity, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque...

More technical details, like: centre of gravity, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, service brake - location, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - stabiliser spread, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, stabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, stabilised lift capacity - maximum, stabilised lift capacity - to max height, stabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No

Download datasheets (PDF)
